Chapter 1
Introduction
1-1 Overview
The SuperServer 6018R-MT/6018R-MTR is comprised of two main subsystems: the
SC813MFTQ-400CB/R400CB 1U chassis and the X10DRL-i serverboard. Please
refer to our web site for information on operating systems that have been certied
for use with the SuperServer 6018R-MT/6018R-MTR (www.supermicro.com).
In addition to the serverboard and chassis, various hardware components have
been included with the system, as listed below:
•Four 4-cm high-performance fans (FAN-0147L4)
•Two passive heat sinks (SNK-P0047PD)
•One air shroud (MCP-310-19015-0N)
•One PCI-Express 3.0 x8 riser card (RSC-RR1U-E8)
•SATA Accessories
One SATA backplane (BPN-SAS-815TQ)
Four 3.5" hard disk trays (MCP-220-00075-0B)
One SGPIO cable (CBL-CDAT-0661) and one SATA cable set (CBL-0186L)
•SuperServer 6018R-MT/6018R-MTR Quick Reference Guide
Note: For your system to work properly, please follow the links below to download
all necessary drivers/utilities and the user’s manual for your server.
•Supermicro product manuals: http://www.supermicro.com/support/manuals/
•Product drivers and utilities: ftp://ftp.supermicro.com
•Product safety info: http://super-dev/about/policies/safety_information.cfm
Chapter 1: Introduction
1-1
