Chapter 1
Introduction
1-1 Overview
The SuperServer 5016I-MT/5016I-MTF is a high-end server comprised of two main
subsystems: the SC813MTQ-350 1U chassis and the X8SIE/X8SIE-F motherboard.
Please refer to our web site for information on operating systems that have been
certifi ed for use with the SuperServer 5016I-MT/5016I-MTF (www.supermicro.com).
Note: a complete list of safety warnings is provided on the Supermicro web site at
http://www.supermicro.com/about/policies/safety_information.cfm
In addition to the motherboard and chassis, various hardware components have
been included with the SuperServer 5016I-MT/5016I-MTF, as listed below:
• Four 4-cm high-performance fans (FAN-0065L4)
• One passive heatsink (SNK-P0046P)
• One PCI-Express 2.0 x16 riser card (CSE-RR1U-E16)
• One slim DVD-ROM drive (DVM-TEAC-DVD-SBT or DVM-PNSC-DVD-SBT)
• One USB adapter for DVD-ROM (CDM-USATA-G)
• One DVD-ROM cable (CBL-0341L)
• SATA Accessories
One SATA backplane (CSE-SAS-815TQ)
One SATA cable set (CBL-0186L)
One SGPIO cable (CBL-0157L)
Four hot-swap hard disk trays (MCP-220-00003-01)
• One SuperServer 5016I-MT/5016I-MTF User's Manual
• One rackmount rail kit (CSE-PT8)
Chapter 1: Introduction
1-1
