1. CONFIGURATION OVER WEB BROWSER

Continued from previous page

Item Description

Proﬁle Current proﬁle – standard or alternative proﬁles (proﬁles are used

for example to switch between different modes of operation)

Supply Voltage Supply voltage of the router

Temperature Temperature in the router

Time Current date and time

Uptime Indicates how long the router is used

Table 3: System Information

1.3 Mobile WAN status

This item is not available for industrial router XR5i v2.

The Mobile WAN menu item contains current information about connections to the mobile

network. The ﬁrst part of this page (Mobile Network Information) displays basic information

about mobile network in which the router is operated. There is also information about the

module, which is mounted in the router.

Item Description

Registration State of the network registration

Operator Speciﬁes the operator in whose network the router is operated

Technology Transmission technology

PLMN Code of operator

Cell Cell to which the router is connected

LAC Location Area Code – unique number assigned to each location area

Channel Channel on which the router communicates

Signal Strength Signal strength of the selected cell

Signal Quality Signal quality of the selected cell:

• EC/IO for UMTS and CDMA (it’s the ratio of the signal received

from the pilot channel – EC – to the overall level of the spectral

density, ie the sum of the signals of other cells – IO)

• RSRQ for LTE technology (Deﬁned as the ratio

N ×RSRP

RSSI

)

• For EDGE technology (router ER75i v2) value is not available

Neighbours Signal strength of neighbor ing hearing cells

Manufacturer Module manufacturer

Continued on next page
