1. CONFIGURATION OVER WEB BROWSER

Continued from previous page

Item Description

MTU Maximum packet size that the equipment is able to transmit

Rx Data Total number of received bytes

Rx Packets Received packets

Rx Errors Erroneous received pac kets

Rx Dropped Dropped received packets

Rx Overruns Lost received packets because of overload

Tx Data Total number of sent bytes

Tx Packets Sent packets

Tx Errors Erroneous sent packets

Tx Dropped Dropped sent packets

Tx Overruns Lost sent packets because of overload

Uptime Indicates how long the connection to mob. network is established

Table 1: Mobile connection

1.2.2 Primar y LAN

Items displayed in this part have the same meaning as items in the previous part. Moreover,

there is information about the MAC address of the router (MAC Address item).

1.2.3 Peripheral Ports

Item Description

Expansion Port 1 Expansion port ﬁtted to the position 1 (None indicates that this

position is equipped with no port)

Expansion Port 2 Expansion port ﬁtted to the position 2 (None indicates that this

position is equipped with no port)

Binary Input State of binary input

Binary Output State of binary output

Table 2: Peripheral Ports

1.2.4 System Information

Item Description

Firmware Version Information about the ﬁrmware version

Serial Number Serial number of the router (in case of N/A is not available)

Continued on next page
