Functions & Software Features
Conel routers enhanced functionality incorporates self-diagnostics
and a HW watchdog to ensure secure and consistent operation and
ultra-reliable wireless connections.
For critical applications, these routers offer wireless redundancy
through dual SIM failover with SMS and email messaging and
control capability for remote alerts and resets. They support the
most commonly used LAN/WAN network protocols and Conel’s
custom software allows for easy, flexible and effective networking
and management.
Networking
• DHCP: automatic IP addressing in LAN network
• NAP/PAT: IP address and port translation
• Firewall: filtering of addresses, ports, protocols
• VRRP: virtual backup router function
• DynDNS client: access to the dynamic IP address
• VLAN 802.1Q: virtual LAN
• QoS: quality of service
• PPPoE Bridge: PPP over Ethernet Bridge mode
• Dial-in: communicate over dial CSD call
• NTP client, NTP server: time synchronization
2× SIM for all FULL version wireless routers
• Back-up by switching between two independent mobile
networks
• Switch when data limit is exceeded, when roaming is detected
or by any other programmable option
VPN Tunnelling
• IPSec, OpenVPN, PPTP, L2TP, EasyVPN, GRE
• Authentication by certificates, shared keys, name/password
5
Remote Router Supervision & Mass Network Management
• HTTP/HTTPS, Telnet/SSH for local and remote configuration and firmware updates
• Automatic configuration and firmware updates from FTP/HTTP server by schedule
• Up to 4 independent configuration profiles can be stored and remotely switched using scripts,
SMS messages, I/O, etc.
• Additional software for easy networking and monitoring, like SmartCLUSTER and R-SeeNet
Diagnostics
• Detailed logs of operational information, including signal status and data traffic
• Signal level data, cell identifiers and data traffic are saved in router’s memory for up to 2 months
• SNMP: router diagnostics, communication with I/O and MBUS
• LED indication: signal strength, connection status, ports
SMS & E-mail Info
• Information about status, connection or disconnection and many other parameters
• SMS control: on/off connection, switching SIM, router profile, I/O
• SMS communication: AT commands (RS232 and TCP/IP), I/O or HTTP
Modular LINUX Software Environment
Open LINUX based system allows use of common LINUX commands, scripts and other features. Conel
routers offer an extension of standard firmware with optional software plug-ins. You can create your
own plug-in and simply apply it to the router. The router has 128kb non-volatile RAM memory, ready
for data collection and processing applications.
Software Plug-ins
• Easy VPN client: secure, encrypted VPN
• Dynamic routing protocols: BGP, OSPF, RIP, IS-IS
• IGMP: multicast protocols
• MODBUS RTU/TCP gateway and mapping: convert data from RTU to TCP/IP format
• Captive Portal
ROUTER MOBILE WIRELESS NETWORK TECHNOLOGY MAX DOWNLOAD MAX UPLOAD
ER75i v2 GPRS/EDGE router GPRS/EDGE 236,8 Kbit/s 118,4 Kbit/s
UR5i v2 UMTS/HSPA+ router UMTS/HSPA+ & GPRS/EDGE 14,4 Mbit/s 5,76 Mbit/s
UR5i v2 Libratum router UMTS/HSPA+ & GPRS/EDGE 14,4 Mbit/s 5,76 Mbit/s
LR77 v2 LTE router LTE & UMTS/HSPA+ & GPRS/EDGE 100 Mbit/s 50 Mbit/s
CR10 v2 CDMA router CDMA 2000 1X, EV-DO Rev. A, B, 450 MHz bands 14,7 Mbit/s 5,4 Mbit/s
UCR11 v2 UMTS/CDMA router UMTS/HSPA+ & GPRS/EDGE & CDMA2000 1X, EV-DO Rev A, B, 450 MHz bands 21,1 Mbit/s 5,76 Mbit/s
Bivias v2 router by the modules by the modules by the modules
XR5i v2 LAN router ETHERNET 10/100 100 Mbit/s 100 Mbit/s
Choose the right model by data transfer technology:
LTE/HSPA+/UMTS/CDMA/EDGE/GPRS Routers
www.conel.com
PRO–2014-01-1-EN-rev09
ER75i v2 UR5i v2 UR5i v2 Libratum LR77 v2 CR10 v2 UCR11 v2 Bivias v2
Frequency Bands
GSM 900, 1800 MHz
D D D D D D
GSM 850, 1900 MHz
DDDD DD
UMTS (WCDMA/FDD) 900, 2100 MHz
DDD DD
UMTS (WCDMA/FDD) 850, 1900 MHz
DDD DD
LTE 800, 900, 1800, 2100, 2600 MHz
DD
CDMA 2000 450 MHz
DDD
