M5350

3G Mobile Wi-Fi User Guide

-7-

Chapter 3. Quick Installation Guide

This chapter will guide you to quickly set up the basic functions for your M5350 3G Mobile

Wi-Fi.

3.1 System Requirements

 SIM card with Internet access enabled.

 Computer with wireless network card.

 Web browser, such as Mozilla Firefox, Internet Explorer, Google Chrome, Apple Safari, etc.

3.2 TCP/IP Configuration

The default IP address of the M5350 3G Mobile Wi-Fi is 192.168.0.1, and the default Subnet

Mask is 255.255.255.0, which values can be changed as you desire. In this guide, we use all

the default values for description, and take the configuration in Windows XP for example. While,

Pads or Wi-Fi cellphones by default obtain IP address and DNS server address automatically,

so you can just skip this step and continue with the 3.3 Wireless Connection.



Note:

Before configuration, please make sure your computer has been equipped with a wireless

network adapter.

 Obtain an IP address automatically

1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC.

Please refer to Appendix B: Configuring the PC for the detailed instructions.

2) Then the built-in DHCP server will assign an IP address for the PC.

 Configure the IP address manually

Set up the TCP/IP Protocol manually for your PC. Please refer to Appendix B: Configuring

the PC for the detailed instructions.

3.3 Wireless Connection



Note:

To log in the Device‟s web-based management page, you need to first connect to the wireless

network of the Device.

1. Click the icon at the bottom of your desktop.

2. Click the refresh button , and then select the SSID of M5350 and then click Connect.
