Tp-Link m5360 [15/51] Quick installation guide

M5360

3G Mobile Wi-Fi, 5200mAh Power Bank User Guide

-8-

Chapter 3. Quick Installation Guide

This chapter will guide you to quickly set up the basic functions for your M5360.

3.1 System Requirements

 SIM card with Internet access enabled.

 Computer supports only the 2.4GHz wireless band.

 Web browser, such as Mozilla Firefox, Internet Explorer, Google Chrome, Apple Safari, etc.

3.2 TCP/IP Configuration

The default IP address of the M5360 is 192.168.0.1, and the default Subnet Mask is

255.255.255.0, which values can be changed as you desire. In this guide, we use all the default

values for description, and take the configuration in Windows 7 for example. While, Pads or

Wi-Fi cellphones by default obtain IP address and DNS server address automatically, so you

can just skip this step and continue with the

3.3 Connect to the Internet.



Note:

Before configuration, please make sure your computer has been equipped with a wireless

network adapter.

 Obtain an IP address automatically

1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC.

Please refer to

Appendix B: Configuring the PC for the detailed instructions.

2) Then the built-in DHCP server will assign an IP address for the PC.

 Configure the IP address manually

1) Set up the TCP/IP Protocol for your PC. Please refer to

Appendix B: Configuring the PC for

the detailed instructions.

2) Configure the network parameters. The IP address is 192.168.0.X ( X stands for any

number from 2 to 254), Subnet Mask is 255.255.255.0, and Gateway is 192.168.0.1 (the

device's default IP address).

3.3 Connect to the Internet



Note:

To log in the Device’s web-management page, you need to first connect to the wireless network

of the Device.

1. Click the icon at the bottom of your desktop.

2. Click the refresh button

, and then select the SSID of M5360 and then click Connect.
