Thermaltake Element T, VK90001N2Z, w/o PSU, black [2/12] Contents
Макгруп McGrp.ru
Задайте вопрос
Зарегистрироваться

Thermaltake Element T, VK90001N2Z, w/o PSU, black [2/12] Contents

Thermaltake Element T, VK90001N2Z, w/o PSU, black [2/12] Contents
1 2
Chapter 1. Product Introduction
Specification
1.0
02
Chapter 2. Installation Guide
2.0
2.1
2.2
2.3
2.4
2.5
2.6
2.7
2.8
Side Panels Disassembly
Motherboard Installation
5.25” Drives Installation
3.5” HDD Installation
2.5” HDD Installation
Power Supply Unit (PSU) Installation
PCI Card Installation
Keyboard & Mouse Security Lock Usage
20 cm fan Installation (optional)
03
04
05
07
09
10
11
12
13
Contents
Chapter3 Leads Installation Guide
Case LED connection
USB 2.0 connection
Audio connection
3.0
3.1
3.2
14
14
14
Chapter4 Other
Toughpower/ Purepower/
TR2 power supply series (optional)
4.0
19
Specification
Model
Case Type
Net Weight
Dimension
(H*W*D)
Cooling System
Drive Bays
- Accessible
- Hidden
Material
Color
Expansion Slots
Motherboards
I/O Ports
LCS Upgradable
PSU
11
3 x 5.25” , 1 x 3.5”
6 x 3.5” , 1 x 2.5”
SECC
Black
7
9.6” x 9.6” (Micro ATX), 12” x 9.6” (ATX)
USB 2.0 x 2, HD Audio x 1
Supports 1/2” , 3/8” , 1/4” water tube
Standard PS2 PSU (Optional)
VK90001N2Z
Middle Tower
6.95 kg / 15.32 lb
480 x 210 x 525 mm
(18.9 x 8.3 x 20.7 inch)
Front (intake) : Optional
200 x 200 mm fan x 1 or 120 x 120 mm fan x 2 or
140 x 140 mm fan x 2
Rear (exhaust) :
120 x 120 x 25 mm Turbo fan (1400rpm,17dBA)
Top (exhaust) :
200 x 200 x 20 mm silent fan (800rpm,14dBA)
Side (intake) : Optional
230 x 230 mm fan x 1 or 120 x 120 mm fan x 1
Figrure
Parts Name
Q'ty
Used for
Stand-off
#6-32 screw
M3 thumb screw
#6-32 thumb screw
M3 screw
Snap bushing
4
9
6
20
4
2
M/B tray
M/B tray
CD-ROM
3.5” HDD
FDD
LCS
M3 screw
4
4
2.5” HDD
#6-32 screw
8
Front Fan
Fan spacer
Front fan
藍色線條為尺寸標示，請勿印刷上去！
刀模線
250 mm
176 mm
