TM
Toughpower Grand
TM
Toughpower Grand
7. EMI & SAFETY
MEET CE
MEET GOST-R
MEET CUL/UL
MEET TUV
MEET CB
MEET CE
EMI Regulatory
SAFETY Standards
8. Environments
Operating temperature
Operating humidity
MTBF
0℃ to 50℃
20% to 90%
120,000 hrs minimum
9. Trouble-Shooting
If the power supply fails to function properly, please follow the troubleshooting guide before
application for service:
1. Is the power cord plugged properly into electrical outlet and into the power supply AC inlet?
2. Please make sure the “I/O” switch on the power supply is switched to “I” position.
3. Please make sure all power connectors are properly connected to all the devices.
4. Please turn-off and turn-on the power supply with the I/O switch few times with about 0.5 second in
the OFF state to reset the PSU.
5. If connected to a UPS unit, is the UPS on and plugged in?
If the power supply is still unable to function properly after following the above instruction, please
contact your local store or Thermaltake branch office for after sales service. You may also refer to
Thermaltake’s website for more technical support:
www.thermaltake.com
03
6. Output Specification
Voltage
Max Load
Combined Wattage
Max Load
Combined Wattage
Max Load
Combined Wattage
Input Voltage: 100V-240V; Frequency: 50Hz - 60Hz
+3.3V
+12V1
+5V
+12V2 -12V
+5VSB
25A 71A25A
N/A
0.8A 6A
180W 850W 9.6W 30W
N/A
Model
850W
1050W
1200W
25A 40A25A 80A 0.8A 6A
180W 1050W 9.6W 30W
25A 40A25A 85A 0.8A 6A
180W 1200W 9.6W 30W
4. Installation Steps
Note: Make sure that your system is turned off and unplugged. Disconnect the AC power
cord from your old power supply.
1. Install the PSU into the case with the four screws provided. Include the two vibration absorbent gaskets
(recommended) that come with the unit.
2. Connect the 24pin Main Power Connector to your motherboard.
3. Connect the 8pin or 4pin connector for the CPUs. For motherboard that only requires a 4pin ATX 12V
(CPU) connector, please detach a 4pin connector from the 4+4pin ATX 12V connector and connect it to
the motherboard. (Either one of the 4pin from the 4+4pin ATX 12V connector will work)
4. Connect the modular cables from the cables accessories pack to the socket on the power supply as
needed.
5. Connect the SATA devices (if applicable) to the power supply using the SATA cables provided. ie; hard
drives, CD/DVD drives
6. Connect any devices that may use the 4pin peripheral connectors. ie; hard drives, CD/DVD drives or
case fans.
7. If your graphic card requires PCI-E power connector, please connect corresponding PCI-E connector
instructed by your graphic card’s user manual. Please note the power supply utilizes a unique 6+2pin
PCI-E connector that can be effectively used as a single 8pin or 6pin PCI-E connector. To use it as a
6pin PCI-E connector, please detach the 2pin connector from the 6+2pin connector.
DO NOT PLUG THE PCI-E CABLE INTO THE CPU POWER CONNECTION.THIS WILL DAMAGE YOUR
SYSTEM.
8. Connect the AC power cord to the power supply AC inlet and turn the switch to “I” position
5. Product Features
- Compliance with Intel ATX 12V 2.3 & SSI EPS 12V 2.92 standards.
- 80 PLUS Gold certified – with 87-93% extreme high efficiency @ 20-100% load to cut down electric cost.
- 24/7 @ 50℃: Guaranteed to deliver 850W/1050W/1200W continuous power.
- Pure aesthetic design with uncompromising performance.
- Proprietary dual ball bearing 14cm flower-shape fan enables longer lifespan and lowers overall noise
output by dramatically reducing bearing frictions.
- 100% 105℃ (221℉) Japanese made electrolytic & solid state capacitors: provide uncompromised
performance and reliability under the harshest operating environment.
- Double-forward switching circuitry: offers low power loss and high reliability.
- Unparalleled DC to DC converter provides highest efficiency, most stable performance, and perfect
regulation.
- 3oz PCB design reduces heat generation and allows greater efficiency.
- 12Vin1: 850W comes with single +12V rail design providing up to 71A.
- 12Vin2: 1050W comes with dual +12V rails design providing up to 40A for 12V1 and 80A for 12V2. 1200W
comes with dual +12V rails design providing up to 40A for 12V1 and 85A for 12V2.
- FanDelayCool Technology allows 14cm fan to continue to operate 15-30 sec after system shuts-down to
ensure all components are properly cooled.
- Multi-GPU ready: 850W comes with 6 x PCI-E 6+2pin for cutting-edge gaming machine. 1050W/1200W
comes with 8 x PCI-E 6+2pin for cutting-edge gaming machine.
- Auto switching circuitry for universal AC input from 90-264V.
- Active Power Factor Correction (PFC) with PF value of 0.95 at full load.
- High reliability: MTBF>120,000 hours.
- DIMENSION: 5.9”(W) x 3.4”(H) x ˙7.1” (L);150mm(W) x 86mm(H) x 180mm(L)
- Built-in industry grade protections: Over Current, Over Power, Over Voltage, Under Voltage, Over
Temperature and Short-Circuit protection.
- Safety / EMI Approvals: CE, TUV, FCC, UL, CUL, GOST and BSMI certified.
04
