ENGLISH

3.10 CLEANING THE SCREEN

Do not use force when cleaning the screen. Thermostat’s display is made of glass

and can easily be broken as a result of too strong pushing on it. To clear the screen

from dirt and ngerprints, we recommend to use a soft damp cloth. Do not use

aerosol sprays, solvents, alcohol, and abrasive/grinding materials.

4 TECHNICAL SPECIFICATIONS

Operating Voltage 230VAC +10/-15%, 50/60Hz

Device Power Consumption 1,2W

Maximum Load 3600W

Maximum Fuse Size 16A

Adjustment Range +5°C - +40°C

Hysteresis 0,5°C

Cable Sizes 0.5 – 2.5mm

Housing IP21

Sensor 12kΩ

Ambient temperature 0 - +30°C

Size 71mm X 71mm X 52mm

Suitable frame sets JUNG A Creation

5 NORMS / STANDARDS

EN 60730-1 Automatic electrical controls for household and similar use. Part 1:

General requirements

EN 60730-2-9 Automatic electrical controls for household and similar use.

Part 2: Special requirements for temperature limiters

The standards described above also cover the requirements of the EMC (Electro

Magnetic Compatibility) and LVD (Low Voltage Directive) Directives.

6 CONTACT INFORMATION

Thermo Industri AB

Box 7275

10389 Stockholm

SWEDEN

www.thermoindustri.se
