WORKING WITH MULTIPLE MONITORS
If you are using more than one monitor, Intuos will map to the monitors based on how they are configured
in the display properties control panel.
• If more than one monitor is in use and you are in extended monitor mode, the tablet maps to all
monitors as if they were one large display.
• If your monitors are in mirror mode (both monitors display the same content), the tablet maps to the
entire space on each monitor and the screen cursor is displayed on each monitor simultaneously.
See your hardware and operating system documentation for details on configuring your computer and
operating system for use with multiple monitors.
Tips
:
• You can customize the tablet to map to a single monitor or to a portion of the monitor area.
See Tablet to screen mapping
.
• When your system is configured with multiple monitors, you can assign the D
ISPLAY TOGGLE function
to an ExpressKey. This enables you to toggle the current tablet mapping and screen cursor between
the primary display and your other monitors. See working with Display Toggle
.
CONTROL PANEL BASICS
After mastering the basics of using your Intuos tablet, you may want to customize the way touch or pen
input works. The Wacom Tablet control panel is where you customize your Intuos tablet settings.
Control panel overview
Monitor 1 Monitor 2
Example of tablet mapping to the entire system desktop,
which is displayed on two monitors.
