Yealink CP860 [2/2] Certification

CP860

HD IP Conference Phone

Audio features

• Optima HD voice

• 10-feet (3-meter)microphone pickup, can be applied

to medium-sized conference room

• Built in 3-microphone array, 360 degree voice pickup

• 112 mm diameter and 2.7w speaker

• Full-duplex speakerphone with AEC

• Echo cancellation tail length is up to 320ms

• Background noise suppression

• Codecs: G.722, G.711(A/μ), G.729AB, iLBC

• DTMF: In-band, Out-of-band(RFC 2833) and SIP INFO

• VAD, CNG, PLC, AJB, AGC

Phone features

• 1 VoIP account

• Call hold, mute, DND

• Call recording, hotline

• 5-way conferencing calls

• Redial, call waiting, emergency call

• Call forward, call transfer, call return, dial plan

• Ring tone selection/import/delete

• Set date time manually or automatically

• Volume adjustment

Directory

• Loal phonebook up to 1000 entries

• XML/LDAP remote phonebook

• Intelligent search method

• Phonebook search/import/export

• Call history: dialed/received/missed/forwarded

• Black list

Display

• 192x64-pixel graphical LCD with backlight

• 24 total keys: 4 softkey, off-hook key, on-hook key,

redial, mute, volume key, 3 navigation keys

• Phone lock

• National language selection

• Caller ID with name, number

• LCD display logo

Interface

• 1xRJ45 10/100M Ethernet port

• Power over Ethernet (IEEE 802.3af ), class 0

• 2xEX mic port

• 1xUSB2.0 port

• 1xmobile phone/PC port: 3.5mm

• 1xSecurity lock port

Network and security

• SIP v1 (RFC2543), v2 (RFC3261)

• SIP server redundancy supported

• IPv4/IPv6

• NAT transverse: STUN mode

• Proxy mode and peer-to-peer SIP link mode

• IP assignment: static/DHCP

• HTTP/HTTPS web server

• Time and date synchronization using SNTP

• UDP/TCP/DNS-SRV(RFC 3263)

• QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS, DSCP

• SRTP for voice encryption

• Transport Layer Security (TLS)

• HTTPS certificate manager

• AES encryption for configuration file

• Digest authentication using MD5/MD5-sess

• OpenVPN, IEEE802.1X

Management

• Setup wizard

• Configuration: browser/phone/auto-provision

• Auto provision via FTP/TFTP/HTTP/HTTPS for mass

deploy

• Auto-provision with PnP

• Zero-sp-touch, TR-069, SNMP

• Reset to factory, reboot

• Package tracing export, system log

Other physical features

• 4 context-sensitive “soft” keys

• External universal AC adapter (optional):

AC 100~240V input and DC 5V/2A Output

• Power consumption (PSU): 2.8-5.6W

• Power consumption (PoE): 3.9-8.1W

• Dimension(W*D*H): 320mm*260m*52mm

• Operating humidity: 10~95%

• Storage temperature: -10~50°C

Package features

• Qty/CTN: 5PCS

• N.W/CTN: 8.9KG

• G.W/CTN: 9.9KG

• Giftbox size: 334mm*365mm*96mm

• Carton Meas: 500mm*379mm*342mm

YEALINK NETWORK TECHNOLOGY CO., LTD.

Email: sales@yealink.com Website: www.yealink.com

Certification

REACH

IP-PBX Features

• Intercom, multicast paging

• Anonymous call, anonymous call rejection

• Voice mail, distinctive ringtone, call pickup

USB 2.0
