Getting Started
5
3. Click to locate the TFTP root directory you have configured from the local
system.
4. Click Confirm to finish configuring the TFTP server.
The server URL “tftp://IP address of provisioning server/” (e.g., tftp://192.168.1.100/) is
where the IP phone downloads configuration files from.
Before auto provisioning, you need to obtain configuration files. There are 2
configuration files both of which are CFG-formatted. We call these two files Common
CFG file and MAC-Oriented CFG file. IP phones try to download these two configuration
files from the provisioning server during auto provisioning.
IP phones with firmware version 73 or later also support a local configuration file named
as <MAC>-local.cfg. When a user modifies configurations of the base station via the
handset or web user interface, the configurations will be automatically saved to the
<MAC>-local.cfg file on the IP phone.
The <MAC>.cfg and <MAC>-local.cfg files are only effectual for the specific phone.
They use the 12-digit MAC address of the phone as the file name. For example, if the
MAC address of the phone is 0015651130F9, the <MAC>.cfg and <MAC>-local.cfg files
have to be named as 0015651130F9.cfg and 0015651130F9-local.cfg respectively.
However, the Common CFG file is effectual for all phones of the same phone model. The
Common CFG file of the W52P IP DECT phone uses the fixed name “y000000000025.cfg”.
You can export/import the <MAC>-local.cfg file via web user interface. For more
information on how to export/import a local configuration file, refer to Scenario D
Importing or exporting the local configuration file on page 48.
You can ask the distributor or Yealink FAE for the y000000000025.cfg and <MAC>.cfg
The <MAC>-local.cfg file only saves configurations of the base station configured via
the handset or web user interface. Configurations of the handset cannot be saved to the
<MAC>-local.cfg file.
