Getting Started
7
Before auto provisioning, you also need the phone information. For example, MAC
address of the phone and the SIP account information.
MAC Address: The unique 12-digit serial number of the phone. You can obtain it from the
bar code on the back of the base station.
SIP Account Information: This may include SIP credentials such as user name, password
and the address of the registration server. Ask your system administrator for SIP account
information.
Auto provisioning enables W52P IP DECT phones to update themselves automatically
via downloading the y000000000025.cfg and <MAC>.cfg files. Before auto provisioning,
you may need to edit and customize your configuration files. IP phones can only
recognize configuration files using UTF-8 or ANSI encoding. Open the configuration file
using a text editor (e.g., UltraEdit). For more information on configuration parameters in
configuration files, refer to Description of Configuration Parameters in CFG Files on page
69.
When editing the configuration files, learn the following:
The extension “.cfg” of the configuration file name must be in lowercase.
Each line in the configuration files must use the following format and adhere to the
following rules:
variable-name = value
- Associate only one value with one variable.
- Separate variable name and value with an equal sign.
- Set only one variable per line.
- Put the variable and value on the same line, and do not break the line.
- Comment the variable on a separated line. Use the pound (#) delimiter to
distinguish the comments.
The file header “#!version:1.0.0.1” in the configuration files is not a comment and
Can Not be edited or deleted.
