Yealink W52P IP DECT Phones Auto Provisioning Guide
26
triggered to perform auto provisioning, it will request to download the configuration files
from the identified directory on the provisioning server.
The following example assists in explaining the wildcard feature:
You want to deploy SIP-T28P and W52P IP phones simultaneously in your environment. IP
phones are configured to obtain the provisioning server address via DHCP options. The
following details how to deploy the W52P IP DECT phones using wildcard feature.
1. Create two directories on the root directory of provisioning server.
2. Configure the directory name of these two directories to be “T28P” and “W52P”
respectively.
3. Place the associated configuration files to the directories created above.
4. Configure the provisioning server URL on the DHCP server as:
tftp://192.168.1.100/$PN.
5. Configure the value of the parameter “auto_provision.url_wildcard.pn”.
The default value of the parameter “auto_provision.url_wildcard.pn” on the W52P
IP DECT phones is “W52P”. If the directory name is not configured as “W52P”, you
need to configure the value of this parameter to be the directory name on the
W52P IP DECT phones in advance.
During startup, IP phones obtain the provisioning server URL “tftp://192.168.1.100/$PN”
via DHCP option 66, and then replace the character “$PN” in the URL with “W52P” for
the W52P IP DECT phones. When performing auto provisioning, the W52P IP DECT
phones request to download configuration files (y000000000025.cfg and <MAC>.cfg
files) from the provisioning server address “tftp://192.168.1.100/W52P”.
If the URL is configured as “tftp://192.168.1.100/$PN/$MAC.cfg” on the DHCP server, the
W52P IP DECT phones will replace the characters “$PN” with “W52P” and “$MAC” with
their MAC addresses. For example, the MAC address of one W52P IP DECT phone is
00156522f5g3. When performing auto provisioning, the IP phone will only request to
download the 00156522f5g3.cfg file from the provisioning server address
“tftp://192.168.1.100/W52P”.
The value of the parameter “auto_provision.url_wildcard.pn” must be configured in
accordance with the directory name of the provisioning server directory where the
configuration files of the IP phones are located.
