Downloading and Updating Configuration Files
43
#Configure the access URL of the firmware file.
firmware.url = tftp://192.168.1.211/25.73.0.20.rom
2. Trigger the IP phone to perform the auto provisioning process. For more information
on how to trigger auto provisioning process, refer to Configuring the Updating
Mode on page 27.
During auto provisioning, the IP phone first downloads the y000000000025.cfg file, and
then downloads firmware from the root directory of the provisioning server.
The IP phone reboots to complete firmware upgrade, and then starts auto provisioning
process again which is triggered by phone reboot (the power on mode is enabled by
default). It downloads the y000000000025.cfg, 001565221229.cfg and the
001565221229-local.cfg file in sequence from the provisioning server, and then updates
configurations in these downloaded configuration files orderly to the IP phone system.
The IP phone starts up successfully, and the personalized settings are remained after
auto provisioning.
When a user modifies configurations of the base station via the handset or web user
interface, the IP phone will save the personalized settings to the 001565221229-local.cfg
file on the phone, and then periodically (every 5 minutes) upload this file to the
provisioning server.
Operation II
1. Add/Edit the following parameters in the y000000000025.cfg file or the
001565221229.cfg file you want the IP phone to download:
auto_provision.custom.protect = 1
auto_provision.custom.sync = 0
#Configure the access URL of the firmware file.
firmware.url = tftp://192.168.1.211/25.73.0.20.rom
2. Trigger the IP phone to perform the auto provisioning process. For more information
on how to trigger auto provisioning process, refer to Configuring the Updating
Mode on page 27.
During auto provisioning, the IP phone first downloads the y000000000025.cfg file, and
then downloads firmware from the root directory of the provisioning server.
The IP phone reboots to complete firmware upgrade, and then starts auto provisioning
process again which is triggered by phone reboot (the power on mode is enabled by
default). It downloads the y000000000025.cfg and 001565221229.cfg files in sequence
from the provisioning server, and then updates configurations in the downloaded
configuration files orderly to the IP phone system. As the value of the parameter
“auto_provision.custom.protect” is set 1, the IP phone will also update configurations in
the 001565221229-local.cfg file saved on the IP phone. As a result, the personalized
settings are remained after auto provisioning.
