Downloading and Updating Configuration Files
45
remained after auto provisioning.
If value of the parameter “auto_provision.custom.protect” is set to be 0, and the value of
the parameter “auto_provision.handset_configured.enable” is set to 1, the personalized
handset settings will be overridden after auto provisioning. If the value of the parameter
“auto_provision.handset_configured.enable” is set to 0, the handset settings cannot be
changed via auto provisioning no matter what the value of the parameter
“auto_provision.custom.protect” is.
For more information on the configuration parameters of handset settings, refer to
Configuration Parameters on page 38.
The administrator or user wishes to clear personalized settings of the base station.
Scenario Conditions:
The MAC address of the IP phone is 001565221229.
The current firmware of the base station is 25.73.0.1 or later.
Provisioning server URL: tftp://192.168.1.211
The value of the parameter “auto_provision.custom.protect” is 1.
Operations:
You can clear the personalized settings of the base station via the handset or web user
interface.
To clear personalized settings of the base station via the handset:
1. Press to enter the main menu.
2. Select ->System Settings.
3. Select Reset Local Config, and then press the OK soft key.
4. Enter the system PIN (default: 0000).
5. Press the Done soft key.
The LCD screen prompts “Reset Base Local Configuration Now?”.
6. Press the Yes soft key.
The Reset Local Config option on the web user interface and the handset is available
only if the value of the parameter “auto_provision.custom.protect” was set to 1.
If the value of the parameter “auto_provision.custom.sync” was set to 1, the
configurations in the 001565221229-local.cfg file on the provisioning server will be also
cleared after resetting personalized settings of the base station.
