Yealink SIP-T29G [2/2] Sip t29g specifications

Audio Features

> HD voice: HD handset, HD speaker

> Codecs: G.722, G.711(A/μ), G.723, G.729AB,

G.726, iLBC

> DTMF: In-band, Out-of-band(RFC 2833) and SIP

INFO

> Full-duplex hands-free speakerphone with AEC

> VAD, CNG, AEC, PLC, AJB, AGC

IP-PBX Features

> Busy Lamp Field (BLF)

> Bridged Line Apperance(BLA)

> Anonymous call, anonymous call rejection

> Hot-desking

> Message Waiting Indicator (MWI)

> Voice mail

> Call park, call pickup

> Intercom, paging

> Music on hold

> Call completion

> Call recording

Phone Features

> 16 VoIP accounts

> Call hold, mute, DND

> One-touch speed dial, hotline

> Call forward, call waiting, call transfer

> Group listening, SMS, emergency call

> Redial, call return, auto answer

> 3-way conferencing

> Direct IP call without SIP proxy

> Ring tone selection/import/delete

> Set date time manually or automatically

> Dial plan

> XML Browser

> Action URL/URI

> Integrated Screenshots

> RTCP-XR

SIP-T29G Specifications

Learn More

To find out how Yealink solutions can help your organization, visit us at www.yealink.com or mail to sales@yealink.com

Directory

> Loal phonebook up to 1000 entries

> Black list

> XML/LDAP remote phonebook

> Intelligent search method

> Phonebook search/import/export

> Call history: dialed/received/missed/forwarded

Display and Indicator

> 4.3" 480 x 272-pixel color display with backlight

> 16 bit depth color

> LED for call and message waiting indication

> Dual-color (red or green) illuminated LEDs for

line status information

> Wallpaper

> Intuitive user interface with icons and soft keys

> National language selection

> Caller ID with name, number and photo

Other Physical Features

> Stand with 2 adjustable angles

> Wall mountable

> External universal AC adapter (optional):

AC 100~240V input and DC 5V/2A output

> Power consumption (PSU): 1.8-5.4W

> Power consumption (PoE): 2.1-8.0W

> Dimension(W*D*H*T):

244mm*213mm*185mm*54mm

> Operating humidity: 10~95%

> Operating temperature: -10~50°C

Feature keys

> 10 line keys with LED

> 10 line keys can be programmed up to 27 various

features (3-page view)

> 8 features keys: message, headset, conference, hold,

mute, transfer, redial, hands-free speakerphone

> 4 context-sensitive “soft” keys

> 6 navigation keys

> Volume control keys

> Illuminated headset key

Interface

> Dual-port Gigabit Ethernet

> Support Bluetooth headset through USB Dongle

> 1xRJ9 (4P4C) handset port

> 1xRJ9 (4P4C) headset port

> 1XRJ12 (6P6C) EXT port:

Supports up to 6 Expansion Modules for an attendant

console application

> Power over Ethernet (IEEE 802.3af), class 3

USB 2.0

Internet

Network and Security

> SIP v1 (RFC2543), v2 (RFC3261)

> Call server redundancy supported

> NAT transverse: STUN mode

> Proxy mode and peer-to-peer SIP link mode

> IP assignment: static/DHCP/PPPoE

> HTTP/HTTPS web server

> Time and date synchronization using SNTP

> UDP/TCP/DNS-SRV(RFC 3263)

> QoS: 802.1p/Q tagging (VLAN), Layer 3 ToS

DSCP

> SRTP for voice

> Transport Layer Security (TLS)

> HTTPS certificate manager

> AES encryption for configuration file

> Digest authentication using MD5/MD5-sess

> OpenVPN, IEEE802.1X

> IPv6

Management

> Configuration: browser/phone/auto-provision

> Auto provision via FTP/TFTP/HTTP/HTTPS

for mass deploy

> Auto-provision with PnP

> BroadSoft device management

> Zero-sp-touch, TR-069

> Phone lock for personal privacy protection

> Reset to factory, reboot

> Package tracing export, system log

Certifications

Package Features

> Qty/CTN: 5 PCS

> N.W/CTN: 7.2kg

> G.W/CTN: 8.1kg

> Giftbox size: 274mm*258mm*142mm

> Carton Meas: 732mm*286mm*266mm

Addr: 4th-5th Floor, South Building, No.63 Wanghai Road, 2nd Software Park, Xiamen, China

Web: www.yealink.com

Tel: +86-592-5702000

Email: sales@yealink.com

REACH
