Yealink VC110 (VCM60) [5/5] If you cannot achieve good effect at your seat you can move the microphone to a suitable place

Far away from the noise source when installing VCP40

(such as air conditioner or computer host).

VCP40 should be placed in the center of all participants,

make sure that all participants are within the scope of

If you need to connect an expansion microphone, the

arrangement of microphones should make the sound field

to be evenly distributed, then it will avoid echo from

microphone.

VCP40 supports 360-degree audio pickup at a radius of up

to 3 meters.

pickup.

CPE80 expansion microphone is a directional microphone,

which suppo

120-degree audio pickup and should be

rts

faced to the speaker.

VCP40 video conferencing phone provides two MIC ports.

Please choose any one to connect as required.

When the area of the conference room is more than 15

square meters or the distance between a speaker and

VCP40 video conferencing phone is more than 2 meters,

a CPE80 expansion microphone could be connected to

the MIC port on the VCP40 video conferencing phone,

to pick up sound effectively.

The scope indicated by the dotted line has the best effect.

If you cannot achieve good effect at your seat, you can

move the microphone to a suitable place.

CPE80 expansion

VCP40 Video Conferencing Phone

120

microphone

VCP40 Video Conferencing Phone

r=3m

L=1.8m
