Yamaha PSR-530 [105/130] Voice list
![Yamaha PSR-530 [105/130] Voice list](/views2/1019250/page105/bg69.png)
103
578 0 96 100 Smokey
579 0 0 101 Goblins
580 0 64 101 GobSyn
581 0 65 101 50sSciFi
582 0 66 101 Ring Pad
583 0 67 101 Ritual
584 0 68 101 ToHeaven
585 0 70 101 Night
586 0 71 101 Glisten
587 0 96 101 BelChoir
588 0 0 102 Echoes
589 0 8 102 EchoPad2
590 0 14 102 Echo Pan
591 0 64 102 EchoBell
592 0 65 102 Big Pan
593 0 66 102 SynPiano
594 0 67 102 Creation
595 0 68 102 Stardust
596 0 69 102 Reso Pan
597 0 0 103 Sci-Fi
598 0 64 103 Starz
Ethnic
599 0 0 104 Sitar
600 0 32 104 DetSitar
601 0 35 104 Sitar 2
602 0 96 104 Tambra
603 0 97 104 Tamboura
604 0 0 105 Banjo
605 0 28 105 MuteBnjo
606 0 96 105 Rabab
607 0 97 105 Gopichnt
608 0 98 105 Oud
609 0 0 106 Shamisen
610 0 0 107 Koto
611 0 96 107 T. Koto
612 0 97 107 Kanoon
613 0 0 108 Kalimba
614 0 0 109 Bagpipe
615 0 0 110 Fiddle
616 0 0 111 Shanai
617 0 64 111 Shanai2
618 0 96 111 Pungi
619 0 97 111 Hichriki
Percussive
620 0 0 112 TnklBell
621 0 96 112 Bonang
622 0 97 112 Gender
623 0 98 112 Gamelan
624 0 99 112 S.Gamlan
625 0 100 112 Rama Cym
626 0 101 112 AsianBel
627 0 0 113 Agogo
628 0 0 114 SteelDrm
629 0 97 114 GlasPerc
630 0 98 114 ThaiBell
631 0 0 115 WoodBlok
632 0 96 115 Castanet
633 0 0 116 TaikoDrm
634 0 96 116 Gr.Cassa
635 0 0 117 MelodTom
636 0 64 117 Mel Tom2
637 0 65 117 Real Tom
638 0 66 117 Rock Tom
639 0 0 118 Syn.Drum
640 0 64 118 Ana Tom
641 0 65 118 ElecPerc
642 0 0 119 RevCymbl
Sound Effects
643 0 0 120 FretNoiz
644 0 0 121 BrthNoiz
645 0 0 122 Seashore
646 0 0 123 Tweet
647 0 0 124 Telphone
648 0 0 125 Helicptr
649 0 0 126 Applause
650 0 0 127 Gunshot
SFX
651 64 0 0 CuttngNz
652 64 0 1 CttngNz2
653 64 0 3 Str Slap
654 64 0 16 Fl.KClik
655 64 0 32 Rain
656 64 0 33 Thunder
657 64 0 34 Wind
658 64 0 35 Stream
659 64 0 36 Bubble
660 64 0 37 Feed
661 64 0 48 Dog
662 64 0 49 Horse
663 64 0 50 Bird 2
664 64 0 54 Ghost
665 64 0 55 Maou
666 64 0 64 Tel.Dial
667 64 0 65 DoorSqek
668 64 0 66 Door Slam
669 64 0 67 Scratch
670 64 0 68 Scratch 2
671 64 0 69 WindChm
672 64 0 70 Telphon2
673 64 0 80 CarEngin
674 64 0 81 Car Stop
675 64 0 82 Car Pass
676 64 0 83 CarCrash
677 64 0 84 Siren
678 64 0 85 Train
679 64 0 86 Jetplane
680 64 0 87 Starship
681 64 0 88 Burst
682 64 0 89 Coaster
683 64 0 90 SbMarine
684 64 0 96 Laughing
685 64 0 97 Scream
686 64 0 98 Punch
687 64 0 99 Heart
688 64 0 100 FootStep
689 64 0 112 MchinGun
690 64 0 113 LaserGun
691 64 0 114 Xplosion
692 64 0 115 FireWork
