Graco ProDispense [3/8] Prodispense system components
![Graco ProDispense [3/8] Prodispense system components](/views2/1193400/page3/bg3.png)
ProDispense System Components
Stop
Start
Manual/
Automatic
Dispense
Remote Operator
Station
50 extra feet of cable allows
the controller to be in a room
separate from the fluid panels
Easy Installation
Installation is easy and integrates
seamlessly with other Graco pumps.
FloSync™ Controller
Provides user-friendly menu navigation and data input.
EasyKey™ pad
Large keys and universal icons
allows for easy data entry.
Flow rate .25-4 gpm (.95-15 lpm)
Viscosity range 10 wt oil - #2 grease
Accuracy ± 1/2 % on dispenses
over one gallon
Resolution 4.73 cc/pulse
Working pressure 1500 psi
Porting sizes
Inlet 1/2" npt(f)
Outlet 1/2" npt(f)
OIL
Flow rate .2-1 gpm (.76-3.8 lpm)
Viscosity range 20 – 5000 cps
Accuracy ± 3% on dispenses
over 12 cc
Resolution .119 cc/pulse
Working pressure 3000 psi
Porting sizes
Inlet 1/4" npt(f)
Outlet 3/8" npt(m)
Air inlet 1/4" npt (f)
GREASE
Flow rate .25-4 gpm (.95-15 lpm)
Viscosity range 1 – 20 cps
Accuracy ± 3% on dispenses
over one gallon
Resolution 25 cc/pulse
Working pressure 250 psi
Porting sizes (inlet) 1/2" npt(m)
(outlet) 1/2" npt(m)
WATER, ANTIFREEZE
