Technical
Data
Maximum
hydraulic input pressure
1500 psi (100 bar
, 10.0 MPa)
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum
pump output pressure
4500 psi (310 bar
, 31.0 MPa)
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Maximum
recommended pump speed
50 cycles per minute – 3.3 gpm (12.5 liter/min)
.
. . . . . . . . . . . . . . . . . . . . . . . . .
Hydraulic
fluid consumption
0.2 gal (0.76 liter) per cycle
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Wetted
parts
See manual 307–728
.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Viton
R
is a registered trademark of the Loctite Corporation.
Pump
Performance Charts
Pump Pressure Developed
Hydraulic
Input
Pressure
Pump Outlet
Pressure
100
psi
(7 bar
, .7 MPa)
300 psi
(21 bar
, 2.1 MPa)
200 psi
( 14 bar
, 1.4 MPa)
600 psi
(41 bar
, 4.1 MPa)
300 psi
( 21 bar
, 2.1 MPa)
900 psi
(62 bar
, 6.2 MPa)
400 psi
(28 bar
, 2.8 MPa) 1200 psi
(83 bar
, 8.3 MPa)
500 psi
(34 bar
, 3.4 MPa) 1500 psi
(104 bar
, 10.4 MPa)
600 psi
(41 bar
, 4.1 MPa) 1800 psi
(124 bar
, 12.4 MPa)
700 psi
(48 bar
, 4.8 MPa) 2100 psi
(145 bar
, 14.5 MPa)
800 psi
(55 bar
, 5.5 MPa) 2400 psi
(166 bar
, 16.6 MPa)
900 psi
(62 bar
, 6.2 MPa) 2700 psi
(187 bar
, 18.7 MPa)
1000 psi
(69 bar
, 6.9 MPa) 3000 psi
(208 bar
, 20.8 MPa)
1
100 psi
(76 bar
, 7.6 MPa) 3300 psi
(229 bar
, 22.9 MPa)
1200 psi
(83 bar
, 8.3 MPa) 3600 psi
(250 bar
, 25.0 MPa)
1300 psi
(90 bar
, 9.0 MPa) 3900 psi
(271 bar
, 27.1 MPa)
1400 psi
(97 bar
, 9.7 MPa) 4200 psi
(292 bar
, 29.2 MPa)
1500 psi
(104 bar
, 10.4 MPa)
4500 psi
(313 bar
. 31.3 MPa)
Pump Output
Pump
Speed
Hydraulic
Fluid
Required
Pump
Output
(Cycles/min) gpm liter/min gpm liter/min
5 1.0 3.8 0.33 1.1
10 2.0 7.6 0.66 2.5
15 3.0 11.4 0.99 3.7
20 4.0 15.1 1.32 5.0
25 5.0 18.9 1.65 6.3
30 6.0 22.7 1.98 7.5
35 7.0 26.5 2.31 8.7
40 8.0 30.3 2.65 10.0
45 9.0 34.1 2.97 11.2
50 10.0 37.8 3.30 12.5
Manual
Change Summary
The
following changes have been added to this manual since the last revision:
D
The entire manual was updated electronically
.
