Stroke length .............................................. Pneumatic: 4.75 in (120.65 mm)

Hydraulic: 4.69 in (119.13 mm)

Maximum fluid operating temperature .......... 180°F (82.3°C)

Air or Hydraulic Inlet Size ............................. 3/4 npt(f)

Package

Part No. Series Ratio DataTrak

Remote

DataTrak

Power

Source

Displacement

Pump Size

258744 A 14:1 Air 500 cc 100 (0.7, 7.0) 1400 (9.7, 97)

258751 A 26:1 x Air 500 cc 100 (0.7, 7.0) 2600 (17.9, 179)

258752 A 26:1 x Air 500 cc 100 (0.7, 7.0) 2600 (17.9, 179)

258753 A 1.6:1 Hydraulic Oil 500 cc 1500 (10, 103) 2300 (15.9, 159)

Part No. Description

24C743 To install a L200CM Check-Mate displacement pump on an existing King air motor

24C744 To install a L500CM Check-Mate displacement pump on an existing King air motor

24D625 To install a L500CM Check-Mate displacement pump on an existing Viscount II hydraulic motor

Technical Specifications

Husky

™

307

3/8 inch Pump

President

®

10:1

450 Cart Mount

Viscount

®

II 3100

on 55 gallon RAM
