GENERAL INFORMATION

The Model 792-20 Dispense Valve is designed for applications that require ON/OFF dispensing of beads

and/or dots. It has dispensing capability for material viscosities ranging from water-type material to high

viscosity epoxies and metal filled pastes. This valve also has a fail-safe design to prevent material dump-

ing in case of a power failure. All wetted parts are disposable for easy maintenance and cleaning. The

Operating and Maintenance Manual

SAFETY INFORMATION

This product should be used only by employees who have been given appropriate training and safety

warnings as set forth in this manual. Read completely before operating.

Warning: Do not exceed 100 psi (6.9 bar) pressure on the operating system or 60 psi (4.1 bar) material

supply pressure. Higher pressures are not required and may cause a serious hazard.

ILLUSTRATION REFERENCES

Throughout this manual you will find references by illustration item number to the illustrations in the

manual. The references are indicated by parentheses around a number such as: (7). Illustrations

represent typical valve configurations. The drawings for your exact model are inserted at the back of the

manual and include the part numbers for ordering replacement parts.

GENERAL ACCESSORIES

Graco | Liquid Control offers a full line of standard and custom accessories for your dispensing needs

Mounting Bases and Brackets

Consult your Dispensit dealer or the factory for details.
