MODEL 802-20 RECOMMENDED SPARE PARTS

Note: These parts are routine supply items or wear parts not covered by warranty for normal wear.

Quantity Description Part Number

1 SEAL KIT,802-20

see assembly drawing for part number

** KRYTOX 203GPL ASSEMBLY LUBRICANT 84/0200-K3/11

Dispense Tubes

Custom Dispense Tubes Available - Consult Factory

Part Number Description

Dispense Tube Sampler Package, 2 each of

Dispense tubes marked *

A1020220-10

** Dispense Tube,5542-HU.037, Pack of 10* A1020157-10

** Dispense Tube,5542-HU.043, Pack of 10 A1020211-10

** Dispense Tube,5542-HU.050, Pack of 10* A1020212-10

** Dispense Tube,5542-HU.060, Pack of 10 A1020087-10

** Dispense Tube,5542-HU.066, Pack of 10 * A1020152-10

** Dispense Tube,5542-HU.080, Pack of 10 * A1020213-10

** Dispense Tube,5542-HU.100, Pack of 10* A1020090-10

** Dispense Tube,5542-PP.068, Pack of 10 A1020153-10

** Dispense Tube,5542-P.100, Pack of 10 A1020088-10

** Dispense Tube,5542-GP.100, Pack of 10 A1020221-10

Note: Last 3 digits of description indicate tube inside diameter in .001” increments.

Note: Tube material is coded in description as HU = TPE Urethane,

P=Natural Polyethylene, PP = Pink Polyethylene, GP = Green Polyethylene

Luer Lock Hub Replacement Needles

Needle length shown is length projecting from LL hub. Other lengths available.

Description Needle Part Number

Needle Sampler Package, 10 each of 14, 16,

18, 20 and 22 gauge ½” long needles

E4000025-50

Needle,LL,14 ga.x ½”, Dark Green,Pack of 50 * E4000001-50

Needle,LL,14 ga.x 1”, Dark Green, Pack of 50 E4000014-50

** Needle,LL,15 ga.x ½”, Orange, Pack of 50 E4000004-50

** Needle,LL,16 ga.x ½”, Purple, Pack of 50 * E4000088-50

** Needle,LL,16 ga.x 1”, Purple, Pack of 50 * E4000005-50

** Needle,LL,18 ga.x ½”, Pin, Pack of 50 * E4000006-50

** Needle,LL,19 ga.x ½”, Brown, Pack of 50 E4000008-50

** Needle,LL,20 ga.x ½”, Yellow, Pack of 50 * E4000009-50

** Needle,LL,22 ga.x ½”, Black, Pack of 50 * E4000011-50

** Needle,LL,23 ga.x ½”, Light Blue, Pack of 50 E4000024-50

* Needles are included in Needle Sampler Package.

** The quantity may vary for your application.
