Graco Python XL 1/4" [3/48] Models
Models
3A3948B 3
Models
NOTE: See the Configuration Number Matrix, page 4, to find the plunger and pneumatic motor size for your unit.
Plunger Size
Pneumatic
Motor Size
Maximum Working Pressure
psi (MPa, bar)
Maximum Pneumatic Inlet Pressure
psi (MPa, bar)
1/4 in.
3.5 in.
12,000 (82.7, 827) 61 (0.42, 4.2)
3/8 in. 8500 (58.6, 586)
100 (0.69, 6.9)
1/2 in. 4800 (33.1, 331)
5/8 in. 3000 (20.7, 207)
3/4 in. 2000 (13.8, 138)
