STEP 3:

Once the screws are fixed in

the wall, insert the four screw

heads through the large parts

of the keyhole

-shaped

apertures, and then slide the

EDS downwards, as indicated.

Tighten the four screws for

added

stability.

ATEX Information

1. Certificate number DEMKO 09 ATEX 0906311X

2. Ambient range (-40°C ≤ Tamb ≤ 75°C)

3. Certification string (Ex nA nC IIC T4 Gc)

Standards covered (EN 60079-0:2012, EN 60079-15:2010)

5. The conditions of safe usage:

• Subject devices are for use in ambient temperature -40°C

≤Tamb ≤ +75°C.

• Subject devices are to be installed in an IP54 enclosure.

•

Subject devices are for use in an area of not more than pollution

degree 2 in accordance with IEC 60664-1.

• Subject devices are to use Conductors suitable for use in an

ambient temperature of 100°C must be used for the Power

Supply Terminal.

Wiring Requirements

WARNING

Safety First!

Turn

the power off before disconnecting modules or wires. The

proper

power supply voltage is listed on the product label. Check

the voltage of your power source to make sure you are using the

correct voltage. Do NOT use a voltage greater than

what is

specified on the product label.

These devices must be supplied by a

AELV source as defined in

the Low Voltage Directive 2006/95/EC and 2004/108/EC.
