2
www.moxa.com
info@moxa.com
Ethernet Media Converters and Extenders
Specifications
Technology
Standards:
IEEE 802.3 for 10BaseT
IEEE 802.3u for 100BaseT(X) and 100BaseFX
IEEE 802.3ab for 1000BaseT(X)
IEEE 802.3z for 1000BaseX
IEEE 802.3x for Flow Control
IEEE 802.1D-2004 for Spanning Tree Protocol
IEEE 802.1w for Rapid STP
IEEE 802.1Q for VLAN Tagging
IEEE 802.1p for Class of Service
IEEE 802.1X for Authentication
IEEE 802.3ad for Port Trunk with LACP
ITU G.993.2 for very high speed digital subscriber line transceivers 2
Management: SNMP v1/v2c/v3, LLDP, Syslog, RMON, DHCP Server/
Client, DHCP Option 66/67/82, BootP. TFTP, SMTP, RARP, Telnet,
SNMP Inform, Flow Control, Back Pressure Flow Control
Filter: 802.1Q VLAN, Port-Based VLAN, GVRP, IGMP v1/v2/v3, GMRP
Redundancy Protocols: STP, RSTP, MSTP, Turbo Ringv1/v2, Turbo
Chain, Link Aggregation
Security: RADIUS, TACACS+, SSL, SSH
Time Management: SNTP, NTP Server/Client
Industrial Protocols: EtherNet/IP, PROFINET IO, Modbus TCP
MIB: MIB-II, Ethernet-Like MIB, P-BRIDGE MIB, Q-BRIDGE MIB,
Bridge MIB, RSTP MIB, RMON MIB Group 1, 2, 3, 9
Interface
DSL Port: RJ-11 (RJ45 connector) or detachable 2-contact terminal
block
RJ45 Ports: 10/100BaseT(X) auto negotiation speed, Full/Half duplex
mode, and auto MDI/MDI-X connection
Console Port: USB-serial console (Type B connector)
LED Indicators: PWR1, PWR2, FAULT, STATE, LINK/ACT, CO/CPE,
10/100 (Fast Ethernet port), MSTR/HEAD, CPLR/TAIL, DSL BYPASS
Alarm Contact: 1 relay output with current carrying capacity of 1 A @
24 VDC
Storage Port: USB storage port (Type A connector)
Button: Reset button
Digital Inputs: 1 input with the same ground, but electrically isolated
from the electronics.
•+13to+30Vforstate“1”
•-30to+3Vforstate“0”
•Max.inputcurrent:8mA
Switch Properties
MAC Table Size: 16K
Packet Buffer Size: 1.5 MB for Fast Ethernet side; 8 KB for DSL side
Priority Queues: 4
Max. Number of Available VLANs: 64
VLAN ID Range: VID 1 to 4094
IGMP Groups: 256
Physical Characteristics
Housing: Metal, IP30 protection
Dimensions: 70 x 111 x 135 mm (2.76 x 4.37 x 5.39 in)
Weight: TBD
Installation: DIN-rail mounting, wall mounting (with optional kit)
Altitude: Up to 2000 m
Note:ContactMoxaforproductsguaranteedtofunctionathigheraltitudes.
Environmental Limits
Operating Temperature:
StandardModels:-10to60°C(14to140°F)
WideTemp.Models:-40to75°C(-40to167°F)
Storage Temperature: -40 to 85°C (-40 to 185°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Power Requirements
Input Voltage:
LVModels:12/24/48VDC,redundantdualinputs
HVModels:110/220VDC/VAC
Operating Voltage:
LVModels:9.6to60VDC
HVModels:88to300VDC,85to264VAC
Input Current: TBD
Connection: 5-pin terminal block
Overload Current Protection: Present
Reverse Polarity Protection: Present
Standards and Certifications
Safety: UL 61010-2-201, EN 60950-1 (LVD) (In plan)
EMC: EN 55022/24
EMI: CISPR 22, FCC Part 15B Class A
EMS:
EN61000-4-2(ESD):Contact:8kV;Air:15kV
EN61000-4-3(RS):80MHzto1GHz,10V/m
EN61000-4-4(EFT):Power4kV
EN61000-4-5(Surge):Power4kV
EN 61000-4-6 (CS) 150 kHz to 80 MHz, 10 V/m
EN 61000-4-8 (PFMF)
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Traffic Control: NEMA TS2 (In plan)
Rail Traffic: EN 50121-4 (In plan)
Vibration: IEC 60068-2-6
Note:PleasecheckMoxa’swebsiteforthemostup-to-datecerticationstatus.
MTBF (mean time between failures)
Time: TBD
Standard: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
