Pioneer CDJ-500II [16/16] Specifications
![Pioneer CDJ-500II [16/16] Specifications](/views2/1019564/page16/bg10.png)
16
En
<DRB1223>
Printed in Japan <DRB1223-A>
PIONEER ELECTRONIC CORPORATION
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153, Japan
PIONEER NEW MEDIA TECHNOLOGIES, INC.
2265 East 220th Street, Long Beach, California 90810, U.S.A.
PIONEER ELECTRONICS OF CANADA, INC.
300 Allstate Parkway, Markham, Ontario L3R OP2, Canada
Published by Pioneer Electronic Corporation.
Copyright © 1997 Pioneer Electronic Corporation.
All rights reserved.
Type of error
TOC READ ERROR
PLAYER ERROR
PLAYER ERROR
MECHANICAL TIME OUT
MECHANICAL TIME OUT
MECHANICAL TIME OUT
Cause = Remedy
A disc is dusty or dirty.
= Clean the disc.
A disc is cracked.
= Replace the disc.
Foreign object is in the disc
compartment. = Remove it.
Error display
When the player cannot be operated correctly, an error code number appears in the display window. When the displayed error
code number is in the table below, confirm the cause of the trouble and solve it. If the cause of trouble is unknown, remedy is
too difficult or the same error code number is displayed after it is remedied, please contact your nearest PIONEER authorized
service center and refer to the error code number.
TROUBLESHOOTING
1. General
System .................Compact disc digital audio system
Power requirements ........................ AC 120 V, 60 Hz
Power consumption ...........................................19 W
Operating temperature...........................+5˚C - +35˚C
(+41°F - +95°F)
Operating humidity......................................5% - 85%
(There should be no condensation of moisture.)
Weight............................................ 4.1 kg (9 lbs 1 oz)
Dimensions ............320(W) X 362.1(D) X 98.5(H) mm
12-5/8(W) X 14-1/4(D) X 3-7/8(H) in.
2. Audio section
Frequency response ...................4 Hz - 20 kHz (EIAJ)
Signal-to-noise ratio................. 106 dB or more (EIAJ)
Dynamic range .......................... 96 dB or more (EIAJ)
Channel separation.................... 98 dB or more (EIAJ)
Total harmonic distortion..........0.004% or less (EIAJ)
Output level........................................................ 2.0 V
Channels ........................................2-channel (stereo)
3. Other terminal
CONTROL ............................................ miniature jack
4. Functions
÷ Top loading disc compartment
÷ Pick-up protector
÷ Sliding type speed control (TEMPO control knob)
÷ Immediate playback
÷ Realtime loop
÷ Reloop
÷ Loop out point adjustment
÷ Master tempo control
÷ Fader start (*)
÷ Fader stop (back cue) (*)
÷ Relay playback (using the CONTROL jack)
÷ Auto cue (ON/OFF)
÷ Cue point monitor
÷ Back cue
÷ Beat search with the Jog dial
÷ Frame search with the Jog dial
÷ Manual search with the Jog dial
÷ High-speed manual search
÷ Cyclical track search
÷ Switching of the TIME display (TIME/REMAIN)
÷ Auto spindle stop
(*)Available when combined with PIONEER DJM-500
or DJM-300 DJ mixer.
5. Accessories
÷ Operating instructions...........................................1
÷ Audio cable ...........................................................1
÷ Control cable .........................................................1
÷ Screws for rack mounting .....................................4
÷ Spacers for rack mounting ....................................4
NOTE:
Specifications and design subject to possible
modification without notice, due to improvements.
SPECIFICATIONS
Maintenance:
In order to ensure the safe and correct function of
this unit, we recommend regular maintenance.
Extended service life can be expected if maintained
properly.
Displayed error
code number
E-72 01
E-83 01
E-83 02
E-91 01
E-91 02
E-91 03
Error contents
TOC data on the disc cannot be read even
after 20 seconds have passed.
A disc cannot be played normally. (GFS NG)
A disc cannot be played normally. (FOCUS
NG)
Mechanism operation is not completed within
the specified time. (CLAMP)
Mechanism operation is not completed within
the specified time. (OPEN)
Mechanism operation is not completed within
the specified time. (INSIDE)
<97F00WZ0H00>
