Moxa EDS-528E-4GTXSFP-LV [11/116] Configuration by web console

Managed Ethernet Switch (UI_2.0_FW_5.x) Getting Started

2-6

4. The Main Menu of the Moxa switch’s Telnet console should appear.

5. In the terminal window, select Preferences… from the Terminal menu on the menu bar.

6. The Terminal Preferences window should appear. Make sure that VT100 Arrows is checked.

7. Use the following keys on your keyboard to navigate the Moxa switch’s Telnet console:

Key Function

Up, down, right, left arrow keys, Tab Move the onscreen cursor

Enter Display and select options

Space Toggle options

Esc Previous menu

NOTE

The Telnet console looks and operates in precisely the same manner as the

USB console.

Configuration by Web Console

The Moxa switch’s web console is a convenient platform for modifying the configuration and accessing the

built-in monitoring and network management functions. You can open the Moxa switch’s web console using a

standard web browser, such as Internet Explorer.

NOTE

When connecting

to the Moxa switch’s Telnet or web console, your PC host and the Moxa switch must be on

the same logical subnet.

NOTE

If the Moxa switch is configured for other VLAN settings, you must make sure your PC host is on the

management VLAN.
