BEFORE OPERATING (PANEL FACILITIES)
12
<DRB1451>
En
1 2 3 4 5 6 7 8
11
1214 13
9
10
Display
1. Segment display x3
Displays folder number, track number, or alphanumeric data.
2. REMAIN
Lights when the track remaining time is displayed.
3. Segment display x3
Displays time (minutes) or alphanumeric data.
4. Segment display x2
Displays time (seconds) or alphanumeric data.
5. Segment display x2
Displays time (frame) or alphanumeric data.
6. TEMPO
Displays the change rate of tempo.
7. MT
Lights when Master Tempo function is ON.
8. WIDE
Lights when the TEMPO control range button is set to WIDE.
9. ±6, ±10, ±16
Lights to display tempo range.
10. BPM
Displays the BPM of the track displayed.
11. Dot matrix display (7x5) x12
Displays text.
12. A.CUE
Lights when Auto Cue function is turned on.
13. Playing address display
Displays the current playback position in a one-track full-scale
graph.
When displaying elapsed time, the graph lights from the left,
and when displaying the remaining time the graph light turns
off from the left.
When remaining time is less than 30 seconds, the graph
flashes slowly, and when remaining time is less than 15 se-
conds the graph flashes rapidly.
14. MEMORY
Lights when a cue/loop point is saved.
About TEXT display
Press the TEXT MODE button to switch the display between
track name/album name/artist name for CD-TEXT. During MP3
playback, the display shows ID3 tag track name (if no ID3 tag is
recorded, the display shows the file name) /ID3 tag album name/
ID3 tag artist name.
Each item can display up to 48 characters of text; text longer
than 10 characters is scrolled.
Text may include alphanumerics and some symbols.
If no text is available, the [NO TEXT] message will be dis-
played.
When a track name is selected in TEXT display, the [ ] icon will
be displayed followed by the track name (with MP3, the ID3 tag’s
title name or file name will be displayed).
Also, during MP3 play, the bit rate will be displayed following the
track name.
CDJ-400
When an album name is selected in TEXT display, the [ ] icon
will be displayed followed by the album name.
Pioneer
When an artist name is selected in TEXT display, the [ ] icon
will be displayed followed by the artist’s name.
Pioneer PRO DJ
When folder search is performed with MP3, the folder name is
displayed during the search.
Pioneer DJ
Time display
Press the TIME MODE button to alternate between elapsed
time (TIME) and the track’s remaining time (REMAIN).
The display mode is saved when the power is turned off.
VYNIL
CUE
REV
Removing the jog sheet
Using the furnished screwdriver, remove the two screws and the
jog plate. The inner jog sheet can then be replaced with another
supplied jog sheet or a graphic of your choice.
Screws
Jog sheet
Jog plate
