- 14 -
LED
Color
Status
Description
Red On
The system failed self-diagnosis on
boot-up.
• RAM Test Fail / System Info. Read Fail
/ Switch Initial Fail / PTP PHY Error.
(+ Green MSTR lit on : HW FAIL)
• FW Checksum Fail / Uncompress Fail.
(+ Green Coupler lit on: SW FAIL)
FAULT
Red On
1. The signal contact is open.
2. ABC Loading/Saving Fail.
3.
The port being disabled because of the
ingress multicast and broadcast
packets exceed the ingress rate limit.
4. Incorrect loop connection in a single
switch.
5. Invalid Ring port connection.
PWR1 Amber
On
Power is being supplied to the main
module’s power input PWR1.
Off
Power is not being supplied to the main
module’s power input PWR1.
PWR2 Amber
On
Power is being supplied to the main
module’s power input PWR2.
Off
Power is not being supplied to the main
module’s power input PWR2.
MSTR/
HEAD
Green
On
1.
The switch is set as the Master of the
Turbo Ring, or as the Head of the
Turbo Chain.
2. POST H.W. Fail (+Stat on and Fault
blinking).
Blinking
1. The switch has become the Ring
Master of the Turbo Ring.
2. The Head of the Turbo
Chain, after the
Turbo Ring or the Turbo Chain is
down.
3. The switch is set as Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. The switch is not the Master of this
Turbo Ring.
2. This switch is set as a Member of the
Turbo Chain.
CPLR/
TAIL
Green
On
1. The switch’s coupling function is
enabled to form a back-up path.
2. When it’s set as the Tail of the Turbo
Chain.
3. POST S.W. Fail (+Stat on and Fault
blinking)
Blinking
1. Turbo Chain is down.
2. The switch is set as Turbo Chain’s
Member and the corresponding chain
port is down.
Off
1. This switch has disabled the coupling
function.
2. This switch is set as a Member of the
Turbo Chain.
