Industrial Ethernet Solutions
ICS-G7748/G7750/G7752
Introduction
Process automation and transportation automation applications
combine data, voice, and video, and consequently require high
performance and high reliability. The ICS-G7748/G7750/G7752 series
full Gigabit backbone switches’ modular design makes network
planning easy, and allows greater flexibility by letting you install up
to 48 Gigabit Ethernet ports plus 4 10 Gigabit Ethernet ports. The
ICS-G7748/G7750/G7752’s full Gigabit capability increases bandwidth
48G/48G+2 10GbE/48G+4 10GbE-port full Gigabit modular managed
Ethernet switches
to provide high performance and the ability to quickly transfer large
amounts of video, voice, and data across a network. The switches
support the Turbo Ring, Turbo Chain, and RSTP/STP redundancy
protocols, and are fanless and come with an isolated redundant
power supply to increase system reliability and the availability of your
network backbone.
• Command line interface (CLI) for quickly configuring major
managed functions
• Supports advanced VLAN capability with Q-in-Q tagging
• Software based IEEE 1588 PTP V2 (Precision Time Protocol) for
precise time synchronization of networks
• DHCP Option 82 for IP address assignment with different policies
• Support EtherNet/IP and Modbus/TCP protocols for device
management and monitoring
• Compatible with EtherNet/IP and PROFINET protocols for
transparent data transmission
• Redundant Gigabit Turbo Ring and Turbo Chain (recovery time <
50 ms @ 250 switches), RSTP/STP, and MSTP* for network redun-
dancy
• IGMP snooping and GMRP for filtering multicast traffic
• IEEE 802.1Q VLAN and GVRP protocol to ease network planning
• QoS (IEEE 802.1p/1Q and TOS/DiffServ) to increase determinism
• Port Trunking for optimum bandwidth utilization
• TACACS+, SNMPv3, IEEE 802.1X, HTTPS, and SSH to enhance
network security
• SNMPv1/v2c/v3 for different levels of network management
• RMON for efficient network monitoring and proactive capability
• Bandwidth management prevents unpredictable network status
• Lock port function for blocking unauthorized access based on MAC
address
• Port mirroring for online debugging
• Automatic warning by exception through e-mail, relay output
• Digital inputs for integrating sensors and alarms with IP networks
• Redundant, dual AC power inputs
Features and Benefits
› Up to 48 Gigabit Ethernet ports plus 4 10G Ethernet ports
› Up to 52 optical fiber connections (SFP slots)
› Fanless, 0 to 60°C operating temperature range
› Modular design for maximum flexibility and hassle-free future
expansion
› Hot swap interface and power modules for continuous operation
› Turbo Ring and Turbo Chain (recovery time < 50 ms @ 250
switches), RSTP/STP, and MSTP for network redundancy
› Isolated redundant power inputs with universal 110/220 VAC
power supply range
