Overview

The Moxa EtherDevice™ EDS-P506A-4PoE Series Ethernet switches

are managed redundant Ethernet switches that come standard with 4

10/100BaseT(X) 802.3at/af (PoE/PoE+) compliant Ethernet ports, and 1

or 2 10/100BaseT(X) Ethernet ports or 1 or 2 100BaseFX (SC/ST-type

connector) fiber ports. The EDS-P506A-4PoE Ethernet switches provide

up to 30 watts of power per PoE port, and allow power to be supplied to

connected devices (such as surveillance cameras, wireless access points,

and IP phones) when power is not readily available or cost-prohibitive to

provide locally. The EDS-P506A-4PoE Ethernet switches are highly

versatile, and their fiber ports can transmit data up to 40 km from the

device to the control center with high EMI immunity. The Ethernet

switches support a variety of management functions, including Turbo

Chain, IEEE 1588 PTP, Turbo Ring, RSTP/STP, IGMP, VLAN, QoS, RMON,

bandwidth management, and port mirroring. The EDS-P506A-4PoE series

is designed especially for security automation applications such as IP

surveillance and gate of entry systems, which can benefit from a scalable

backbone construction and Power-over-Ethernet support.

The EDS-P506A-4PoE can operate from 0 to 60°C or -40 to 75°C for T

models and are designed to withstand a high degree of vibration and

shock. The rugged hardware design makes the EDS-P506A-4PoE Series

perfect for ensuring that your Ethernet equipment can operate in critical

industrial environments, and complies with FCC and CE standards.

NOTE

Throughout this Hardware Installation Guide, we use EDS as an

abbreviation for Moxa EtherDevice Switch.

EDS = Moxa EtherDevice Switch

Package Checklist

The EDS-P506A-4PoE is shipped with the following items. If any of these

items are missing or damaged, please contact your customer service

representative for assistance.

• 1 EDS-P506A-4PoE EtherDevice Switch

• Hardware Installation Guide (this guide)

• CD-ROM with user’s manual and Windows utility

• Moxa product warranty statement

• RJ45 to DB9 console port cable

• Protective caps for unused ports

• DIN-Rail mounting kit (attached to the EDS-P506A-4PoE’s rear panel

by default)
