Moxa Managed Ethernet Switches Getting Started

2-6

NOTE

To connect to the Moxa switch’s Telnet or web console, your PC host and the Moxa switch must be on the same

logical subnet.

NOTE

If the Moxa switch is configured for other VLAN se

ttings, you must make sure your PC host is on the

management VLAN.

NOTE

When connecting to the Moxa switch’s Telnet or web console, first connect one of the Moxa switch’s Ethernet

ports to your Ethernet LAN, or directly to your PC’s Ethernet port. You m

ay use either a straight-

through or

cross

-over Ethernet cable.

NOTE

The Moxa switch’s default IP address is 192.168.127.253.

After making sure that the Moxa switch is connected to the same LAN and logical subnet as your PC, open the

Moxa switch’s web console as follows:

1. Connect your web browser to the Moxa switch’s IP address by entering it in the Address or URL field.

2. The Moxa switch’s web console will open, and you will be prompted to log in. Select the login account

(admin or user) and enter the Password. This password will be required to access any of the consoles (web,

serial, Telnet). If you do not wish to create a password, leave the Password field blank and press Enter.

NOTE

By default, no password is assigned to the Moxa switch’s web, seria

l, and Telnet consoles.

3. After logging in, you may need to wait a few moments for the web console to appear. Use the folders in the

left navigation panel to navigate between different pages of configuration options.
