Moxa TN-5816ABP-WV-T [3/4] Ordering information
![Moxa TN-5816ABP-WV-T [3/4] Ordering information](/views2/1197629/page3/bg3.png)
3
www.moxa.com
info@moxa.com
Industry-specific Ethernet Switches
Ordering Information
8 (0.31)
Ø8 (Ø0.31)
Ø4.5
(Ø0.18)
235 (9.25)
120 (4.72)
220 (8.66)
170 (6.69)
250 (9.84)
21 (0.83)
120 (4.72)21 (0.83)
37 (1.46) 37 (1.46)
M4
M4
M4
M4
M4
M4
M4
M4
M4
M4
M4
M4
177 (6.97)
175.8 (6.92)
108 (4.25)
93 (3.66)
103 (4.06)
15.46
(0.61)
M6
115 (4.53)
50 (1.97)
55 (2.17)
181.4 (7.14)
Dimensions
Unit: mm (inch)
Side View (including
DIN-Rail Mounting Kit)Front View
Rear View
DIN-Rail
Mounting Kit
Side View
Top & Bottom Views
TN-5818A Series
Optional Accessories (must be purchased separately)
Power Cords, M12/M23 Connectors, Protective Caps: See following page
MXview: Moxa industrial network management software with 50, 100, 250, 500, 1000, or
2000 nodes
EDS-SNMP OPC Server Pro: OPC server software that works with all SNMP devices
ABC-01-M12: Configuration backup and restore tool for TN series managed Ethernet
switches, 0 to 60°C operating temperature
Package Checklist
• TN-5816A or TN-5818A series switch
• M12-to-DB9 console port cable
• 2 protective caps for console and relay output ports
• Panel mounting kit
• Documentation and software CD
• Hardware installation guide
• Warranty card
Available Models Port Interface
Power Supply
Conformal
Coating
Wide Temperature
(-40 to 75°C)
Front Cabling Down Cabling
10/100 Base-T(X),
M12 connector
10/100 Base-T(X)
M12 connector
10/100/1000 Base-T(X)
M12 connector,
with bypass relay
WV: 24 to 110 VDC
(16.8 to 137.5 VDC)
TN-5816A Series
TN-5816ABP-WV-T
12 4 – 1 –
TN-5816ABP-WV-CT-T
12 4 – 1
TN-5818A Series
TN-5818A-2GTXBP-WV-T
12 4 2 1 –
TN-5818A-2GTXBP-WV-CT-T
12 4 2 1
Definitions:
1. GTXBP: Gigabit Ethernet copper port with bypass relay
2. WV: Wide Voltage
3. CT: Conformal Coating
Note: Conformal coating is available on request.
