Communication Redundancy Turbo Chain
3-4
Explanation of “Settings” Items
Redundancy Protocol
Setting Description Factory Default
Turbo Ring Select this item to change to the Turbo Ring configuration page.
None
Turbo Ring V2 Select this item to change to the Turbo Ring V2 configuration page.
Turbo Chain Select this item to change to the Turbo Chain configuration page
RSTP Select this item to change to the RSTP configuration page.
None Ring redundancy is not active
Role
Setting
Description
Factory Default
Head Select this switch as Head Switch
Member
Member Select this switch as Member Switch
Tail Select this switch as Tail Switch
Head Role
Setting Description Factory Default
Head Port Select any port of the EDS to be the head port. See the following table
Member Port Select any port of the EDS to be the member port. See the following table
Member Role
Setting Description Factory Default
1st Member port
Select any port of the EDS to be the 1st member port
See the following table
2nd Member port Select any port of the EDS to be the 2nd member port See the following table
Tail Role
Setting Description Factory Default
Tail Port Select any port of the EDS to be the tail port. See the following table
Member Port Select any port of the EDS to be the member port. See the following table
Head Role Default Head Port Default Member Port
EDS-400A Series
EDS-505A/508A Series
The second from the last port The last port
EDS-518A Series Port G1 Port G2
EDS-510A Series Port G2 Port G3
EDS-608/616 The third port of the last module The fourth port of the last module
EDS-611/619 Port G2 Port G3
EDS-728/828 Series Port 1-1 Port 1-2
IKS-6726 Series without Gigabit Ethernet module: Port
1-1
with Gigabit Ethernet module: Port 4-1
without Gigabit Ethernet module: Port
1-2
with Gigabit Ethernet module: Port 4-2
IKS-G6524/G6824 Series
ICS-G7526/G7528/
G7826/G7828 Series
The second from the last port The last port
