Installation in Brief 5
We know you are eager to hear your new MartinLogan
subwoofer, so this section is provided to allow fast and
easy set up. Once you have your subwoofer operation-
al, please take the time to read, in depth, the rest of the
information in this manual. It will give you perspective on
how to attain the greatest possible performance from this
most exacting woofer system.
If you should experience any difficulties in the setup or
operation of your MartinLogan subwoofer, please refer
to the Room Acoustics and Placement sections of the
this manual. Should you encounter a persistent problem
that cannot be resolved please contact your authorized
MartinLogan dealer. They will provide you with the appro-
priate technical analysis to alleviate the situation.
WARNING!
• Hazardous voltages exist inside—do not
remove cover.
• Refer servicing to a qualified technician.
• To prevent fire or shock hazard, do not
expose this module to moisture.
• Turn amplifier off and unplug subwoofer
should any abnormal conditions occur.
• The power cord should not be installed,
removed, or left detached from the speaker
while the other end is connected to an AC
power source.
• The main power switch near the AC inlet shall
remain readily operable.
• No candles or other sources of open flame
should be placed on the speaker.
• No liquids either in glasses or vases should be
placed on speaker.
• Speaker should not be exposed to dripping or
splashing liquids.
• The terminals marked with the lightning bolt
symbol should be connected by an instructed
person or by way of ready made terminals
• The power cord should remain readily oper-
able should any abnormal conditions occur.
Step 1: Unpacking
Remove your new subwoofer from its packing. Note:
Retain original packing materials for future use.
Step 2: Placement
Ideally, place the subwoofer in a corner near the front of the
room. Please see the Placement section (page 16) for more
details.
Step 3: Signal Connection
Use the best cables you can. High quality cables, available
from your specialty dealer, are recommended and will
give you superior performance.
Attach your preamplifier/processor outputs through cables
to the signal input area located on the subwoofer’s rear
panel. Please see the Controls and Connections section
(pages 6–15) for more details.
If you plan to connect your subwoofer using Speaker Level
(high level) inputs, please refer to the 2-Channel Mode
Using Speaker Level Inputs section (page 12 for more
details.
Step 4: Power Connection (AC) (see warning)
Make sure the level knob is set at 0. Plug the subwoofer
into a wall outlet. Review the AC Power Connection section
(page 15) of this manual for more details.
Step 5: Setting the Controls
• Set the Level knob to 3 or 4.
• Set the Power switch to ‘Auto’.
• Set the 25Hz Level knob to 0.
• Set the Phase to 90°.
• Set the Low Pass Filter to the closest setting below the
low-end frequency response of your main speakers.
These settings are only a beginning point. Your subwoofer
will need proper setup to optimize performance. Please
see the Controls and Connections section (pages 6–15) for
more details.
Step 6: Listen and Enjoy
InstallatIon In BrIef
