AirWorks AWK-1131A Introduction
1-3
802.11n (2.4 GHz):
Typ. 20±1.5 dBm @ MCS0/8 20 MHz, Typ. 16±1.5 dBm @ MCS7/15 20 MHz
Typ. 20±1.5 dBm @ MCS0/8 40 MHz, Typ. 16±1.5 dBm @ MCS7/15 40 MHz
802.11a:
Typ. 20±1.5 dBm @ 6 to 24 Mbps, Typ. 19±1.5 dBm @ 36 Mbps,
Typ. 16±1.5 dBm @ 48 Mbps, Typ. 15±1.5 dBm @ 54 Mbps
802.11n (5 GHz):
Typ. 19±1.5 dBm @ MCS0/8 20 MHz, Typ. 14±1.5 dBm @ MCS7/15 20 MHz
Typ. 18±1.5 dBm @ MCS0/8 40 MHz, Typ. 14±1.5 dBm @ MCS7/15 40 MHz
Note: Based on regional regulations, the maximum transmission power allowed on the UNII bands is restricted
in the firmware, as indicated below:
US EU JP
2.4 GHz 20 dBm 20 dBm 20 dBm
5 GHz (UNII-1) 17 dBm 20 dBm 20 dBm
5 GHz (UNII-2) 20 dBm 20 dBm 20 dBm
5 GHz (UNII-2e) 20 dBm 20 dBm 20 dBm
5 GHz (UNII-3) 20 dBm 20 dBm 20 dBm
RX
Receive Sensitivity:
802.11b:
-90 dBm @ 1 Mbps, -88 dBm @ 2 Mbps,
-86 dBm @ 5.5 Mbps, -84 dBm @ 11 Mbps
802.11g:
-85 dBm @ 6 Mbps, -84 dBm @ 9 Mbps,
-83 dBm @ 12 Mbps, -82 dBm @ 18 Mbps,
-80 dBm @ 24 Mbps, -76 dBm @ 36 Mbps,
-70 dBm @ 48 Mbps, -70 dBm @ 54 Mbps
802.11n (2.4 GHz):
-70 dBm @ MCS7 20 MHz, -68 dBm @ MCS15 20 MHz
-65 dBm @ MCS7 40MHz, -63 dBm @ MCS15 40 MHz
802.11a:
-92 dBm @ 6 Mbps, -89 dBm @ 9 Mbps,
-85 dBm @ 12 Mbps, -82 dBm @ 18 Mbps,
-80 dBm @ 24 Mbps, -76 dBm @ 36 Mbps,
-74 dBm @ 48 Mbps, -72 dBm @ 54 Mbps
802.11n (5 GHz):
-70 dBm @ MCS7 20MHz, -67 dBm @ MCS15 20 MHz
-68 dBm @ MCS7 40MHz, -66 dBm @ MCS15 40 MHz
Protocol Support
General Protocols:
Proxy ARP, DNS, HTTP, HTTPS, IP, ICMP, SNTP, TCP, UDP, RADIUS, SNMP, DHCP,LLDP
Interface
Default Antennas:
2 dual
-band omni-directional antennas, 2 dBi, RP-SMA (male)
Connector for External Antennas:
RP-SMA (female)
LAN
Ports: 1, RJ45, 10/100/1000BaseT(X) auto negotiation speed, F/H duplex mode, and auto MDI/MDI-X
connection
Console Port:
RS-232 (RJ45-type)
Reset:
Present
LED Indicators:
PWR, FAULT, STATE, SIGNAL*, WLAN, 10/100/1000 (RJ45 port)
*signal strength indicator
Physical Characteristics
Housing:
Metal, IP30 protection
Weight:
307 g (0.68 lb)
Dimensions:
58 x 115 x 70 mm (2.29 x 4.53 x 2.76 in)
Installation:
DIN-rail mounting (standard), wall mounting (optional)
