Industrial Wireless LAN Solutions

www.moxa.com

Introduction

Speciﬁcations

Industrial IEEE 802.11a/b/g wireless AP/bridge/client

The AWK-3121 AP/bridge/client is ideal for industrial hard to wire

applications, keeping wireless costs under control, and integrating

with existing mobile equipment. The AWK-3121 is compliant with the

industrial standards and approvals, covering operating temperature,

power input voltage, surge, ESD and vibration. Installation is easy,

with either DIN-Rail mounting or distribution boxes, and the DIN-Rail

mounting capability, wide operating temperature range, and IP30

housing with LED indicators make the AWK-3121 a convenient yet

reliable solution for any industrial wireless application.

Advanced Security

• 64-bit and 128-bit WEP (Wired Equivalent Privacy)

• Enable/disable SSID broadcasts

• WPA/WPA2 (Wi-Fi Protected Access) and 802.11i support

• IEEE802.1X/RADIUS support

• Powerful ﬁlters for access control

Speciﬁcations for Industrial-grade Applications

• Redundant DC power inputs

• Long-distance data transmission over 10 km

• Integrated DI/DO for on-site monitoring and warnings

• Signal strength LEDs for easy deployment and antenna alignment

› IEEE 802.11a/b/g compliant

› QoS (WMM) and VLAN for efﬁcient network trafﬁc

› Supports long-distance data transfer and client-based Turbo

Roaming

› Maximum security with WEP/WPA/WPA2/802.11X and powerful

ﬁlters

› -40 to 75°C operating temperature range (T models)

AWK-3121 Series

WLAN Interface

Standards:

IEEE 802.11a/b/g for Wireless LAN

IEEE 802.11i for Wireless Security

IEEE 802.3 for 10BaseT

IEEE 802.3u for 100BaseTX

IEEE 802.3af for Power-over-Ethernet

IEEE 802.1D for Spanning Tree Protocol

IEEE 802.1w for Rapid STP

Spread Spectrum and Modulation (typical):

•DSSSwithDBPSK,DQPSK,CCK

•OFDMwithBPSK,QPSK,16QAM,64QAM

•802.11b:CCK@11/5.5Mbps,DQPSK@2Mbps,

DBPSK@11Mbps

•802.11a/g:64QAM@54/48Mbps,16QAM@36/24Mbps,

QPSK@18/12Mbps,BPSK@9/6Mbps

Operating Channels (central frequency):

US:

2.412 to 2.462 GHz (11 channels)

5.18to5.24GHz(4channels)

EU:

2.412 to 2.472 GHz (13 channels)

5.18to5.24GHz(4channels)

JP:

2.412to2.472GHz(13channels,OFDM)

2.412 to 2.484 GHz (14 channels, DSSS)

5.18to5.24GHz(4channelsforW52)

Security:

•SSIDbroadcastenable/disable

•FirewallforMAC/IP/Protocol/Port-basedltering

•64-bitand128-bitWEPencryption,WPA/WPA2-Personaland

Enterprise (IEEE 802.1X/RADIUS, TKIP and AES)

Transmission Rates:

802.11b:1,2,5.5,11Mbps

802.11a/g:6,9,12,18,24,36,48,54Mbps

TX Transmit Power:

802.11b:

Typ.23±1.5dBm@1to11Mbps

802.11g:

Typ.20±1.5dBm@6to24Mbps,Typ.19±1.5dBm@36Mbps,Typ.

18±1.5dBm@48Mbps,Typ.17±1.5dBm@54Mbps

802.11a:

Typ.18±1.5dBm@6to24Mbps,Typ.16±1.5dBm@36to48Mbps,

Typ.15±1.5dBm@54Mbps

RX Sensitivity:

802.11b:

-97dBm@1Mbps,-94dBm@2Mbps,-92dBm@5.5Mbps,-90

dBm@11Mbps

802.11g:

-93dBm@6Mbps,-91dBm@9Mbps,-90dBm@12Mbps,-88

dBm@18Mbps,-84dBm@24Mbps,-80dBm@36Mbps,-76dBm

@48Mbps,-74dBm@54Mbps
