Industrial USB
2
© Moxa Inc. All rights reserved. Updated Mar. 12, 2015. Specifications subject to change without notice. Please visit our website for the most up-to-date product information.
UPort® 1250 UPort® 1250I
77 (3.031)
111 (4.370)
5.3 (0.209)
77 (3.031)
26 (1.024)
3.84 (0.151)
111 (4.370)
5.3 (0.209)
26 (1.024)
Ordering Information
Available Models
UPort 1250: 2-port RS-232/422/485 USB-to-serial converter
UPort 1250I: 2-port RS-232/422/485 USB-to-serial converter with 2 kV electrical isolation,
adaptor included
Optional Accessories (can be purchased separately)
Mini DB9F-to-TB Adapter: DB9 female to terminal block adapter for RS-422/485 applications
Wall Mount Kit: Metal plates and screws
DK35A: Mounting kit for 35-mm DIN-Rail
Package Checklist
• 1 UPort 1250 or 1250I USB-to-serial
converter
• USB-IF certified cable
• 1 mini DB9 female to terminal block
adapter
• Power adapter (UPort 1250I)
• Documentation and software CD
• Quick installation guide (printed)
• Warranty card
Physical Characteristics
Housing: SECC sheet metal (1 mm)
Weight:
Product only: 180 g (0.40 lb)
Packaged:
UPort 1250: 370 g (0.82 lb)
UPort 1250I: 680 g (1.5 lb)
Dimensions: 77 x 26 x 111 mm (3.03 x 1.02 x 4.37 in)
Environmental Limits
Operating Temperature: 0 to 55°C (32 to 131°F)
Storage Temperature: -20 to 75°C (-4 to 167°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Altitude: Up to 2000 m
Note: Please contact Moxa if you require products guaranteed to function
properly at higher altitudes.
Standards and Certifications
Safety: UL 60950-1
EMC: CE, FCC
EMI: EN 55022 Class A, EN 61000-3-2, EN 61000-3-3, FCC Part 15
Subpart B Class A
EMS: EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN
61000-4-5, EN 61000-4-6, IEC 61000-4-8, IEC 61000-4-11
Green Product: RoHS, CRoHS, WEEE
Power Requirements
Power Consumption:
UPort 1250 (bus power): 360 mA @ 5 VDC
UPort 1250I (12 to 48 VDC external power): 200 mA @ 12 VDC
MTBF (mean time between failures)
Time: 563,179 hrs
Database: Telcordia (Bellcore), GB
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Dimensions
Unit: mm (inch)
