CP-132 Series Introduction

1-4

Features

The Industio CP-132 Series consists of members as follows,

-132 2 RS-422/RS-485 ports, 16C550C UART

-132S 2 RS-422/RS-485 ports, surge protection, 16C550C UART

-132I 2 RS-422/RS-485 ports, isolation protection, 16C550C UART

-132IS 2 RS-422/RS-485 ports, surge and isolation protection, 16C550C UART

The following are the outstanding features of Industio CP-132 Series

• Support 2 independent RS-422 or RS-485 serial ports

• Compact board size (half-size)

• Switch for RS-422/RS-485 selection

• High speed up to 921.6K bps each port

• Switch for RS-485 data control－Automatic Data Direction Control Mode or By RTS Mode

• Jumper for Termination Resistors selection, no more headache for impedance matching

• Reliability－High speed 16C550C Communication Controllers with on-chip hardware flow control

guarantees no data loss

• Provide surge protection for all signal lines, ESD max. 25KV, EFT max. 2KV (CP-132S, CP-132IS)

• Provide optical isolation for all signal lines, max. 2KV DC (CP-132I, CP-132IS)

• Powerful Serial Comm tools－PComm and API-232

• Support drivers for most major industrial platform－Windows NT, Windows 95/98, and DOS

CP-132 Series

Windows NT



Windows 95/98



DOS



Note:

Driver supported by Moxa and shipped with product

Download the newest drivers from the MOXA FTP service

Check List

Upon unpacking the Industio CP-132 Series package, you should find the following items:

• Industio CP-132 Series 2 port serial board×1

• MOXA Software CD-ROM×1, which includes:

 Drivers for MOXA Multiport Async Products

 PComm Lite programming library and utilities for Windows NT/95/98

 API-232 programming library and utility for DOS/Windows 3.x

 User’s Manual (PDF)

• Industio CP-132 Series User’s Manual (This manual)
