Universal PCI Board Software Installation

3-58

3. On the Ports Configuration tab, select a port to configure and click Port Setting.

4. Under Port Number, select a COM number to assign to the serial port. Select Auto Enumerating COM

Number to map subsequent ports in numerical order. For example, if COM 3 is assigned to Port 1, then

COM 4 will be automatically assigned to Port 2.

Select an Rx FIFO Trigger and Tx FIFO Size. The default Rx FIFO Trigger is 120 bytes (high level). The

default Tx FIFO Size is 128 bytes (high level). Select Set the change to all ports to use this setting for all

serial ports on the board.

Tx FIFO Rx FIFO

High 128 120

Middle 64 60

Low 1 1

5. Click OK to approve the settings for the selected port. Continue in the same way to configure the other ports.

When you have finished setting up the ports, click OK to close the Properties window and apply the new

port settings. Click OK again to close the Device Manager and restart the system.
