— 4 — — 5 — — 6 —
5. Pin Assignments
CP-102UL has one female DB25 connector on the board, and CP-102U
has two male DB9 connectors on the board. In this section, we give the
on-board connectors’ pin assignments, and male DB9 pin assignments
for the cable CBL-M25M9x2-50 used with CP-102UL.
Female DB25
y CP-102UL on-board connector
912
Port 0 Port 1
2
5
24 21 1518
Pin Number
RS-232 Signals
Port 0 Port 1
1 ---
2 DCD
3 GND
4 CTS
5 RxD
6 ---
7 ---
8 ---
9 DTR
10 DSR
11 RTS
12 TxD
13 ---
14 ---
15 DTR
16 DSR
17 RTS
18 TxD
19 ---
20 ---
21 DCD
22 GND
23 CTS
24 RxD
25 ---
Male DB9
y CP-102U on-board connector (2 connectors, for Ports 0 and 1)
y Device-side connector for cable CBL-M25M9x2-50 (for use with
CP-102UL)
15
69
Pin Number RS-232 Signals
1 DCD
2 RxD
3 TxD
4 DTR
5 GND
6 DSR
7 RTS
8 CTS
9 ---
Click here for online support:
www.moxa.com/support
The Americas: +1-714-528-6777 (toll-free: 1-888-669-2872)
Europe: +49-89-3 70 03 99-0
Asia-Pacific: +886-2-8919-1230
China: +86-21-5258-9955 (toll-free: 800-820-5036)
2008 Moxa Inc., all rights reserved.
Reproduction without permission is prohibited.
