www.moxa.com
info@moxa.com
Multiport Serial Boards
› PCI Express x 1 compliant
› Low profile form factor fits small-sized PCs
› Supports 128 high-performance serial ports per system
› Dramatically decreases host CPU load
› Modular design makes port expansion easy
› Monitor transmission status with LEDs on the module and two
7-segment displays
› Drivers provided for a broad selection of operating systems
› 460.8 Kbps maximum baudrate
The intelligent C320Turbo PCI Express serial board is an expandable
and versatile COM/TTY solution for RS-232/RS-422 applications that
require connecting up to 128 serial devices to one computer. The
C320Turbo’s on-board CPU and large dual-port memory alleviates the
load of host system resources when performance and scalability are
critical for large-scale systems.
8 to 32-port intelligent PCI Express serial board
Hardware
Comm. Controller: 16C550C or compatible x 8
Bus: PCI Express x 1
Connector: DB25 female
Processor: TI DSP TMS320BC52PJ
Memory: 512 KB
Serial Interface
Number of Ports: 32 per control board (max.)
Serial Standards: RS-232 (RS-422 available with desktop option)
Max. No. of Boards per PC: 4
Performance
Baudrate: 50 bps to 460.8 Kbps
Serial Communication Parameters
Data Bits: 5, 6, 7, 8
Stop Bits: 1, 1.5, 2
Parity: None, Even, Odd, Space, Mark
IRQ: Assigned by BIOS
Serial Signals
RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
RS-422: TxD+/-, RxD+/-, RTS+/-, CTS+/-, GND
Driver Support
Operating Systems: Windows 2000, Windows XP/2003/Vista/2008/7
x86/x64, Linux 2.4, Linux 2.6 x86/x64
Note: Please refer to Moxa’s website for the latest driver support information.
Physical Characteristics
Dimensions: 135 x 67 mm (5.32 x 2.64 in)
Environmental Limits
Operating Temperature: 0 to 55°C (32 to 131°F)
Storage Temperature: -20 to 55°C (-4 to 131°F)
Ambient Relative Humidity: 5 to 95% (non-condensing)
Standards and Certifications
EMC: CE, FCC
EMI: EN 55022, FCC Part 15 Subpart B Class A
EMS: EN 61000-4-2, EN 61000-4-3, EN 61000-4-4
Green Product: RoHS, CRoHS, WEEE
Power Requirements
Power Consumption:
1,160 mA @ 3.3 V
Warranty
Warranty Period: 5 years
Details: See www.moxa.com/warranty
Specifications
Overview
C320Turbo (PCI Express)
