DA-IRIGB-4DIO-PCI104-EMC4 Module Driver and Utility Installation
3-6
7:Set IRIG-B Input Parity Check Mode
-p Source[1-2] (1=Fiber In, 2=Port 1 In),Mode[0-
2] (0=Even, 1=Odd, 2=None);
default value is 2,0
8:Get IRIG-B Output Parity Check Mode
9:Set IRIG-B Output Parity Check Mode
-p Mode[0-1] (0=Even, 1=Odd); default value is 0
10:Get Pulse per second width(ms)
11:Set Pulse per second width(ms)
-p [0-999] (width: 0-999 ms); default value is 0
12:Get input signal type
-p [0-1] 0=Fiber, 1=Port 1 (port[0-1]); default value is 1
13:Set input signal type
-p [0-1],[0-1],[0-1]
(port[0-1]: 0=Fiber 1=Port 1,
signal type[0-1]: 0=TTL, 1=DIFF,
inverse[0-1]: 0=No inverse 1=Inverse)
default value is 1,1,0
14:Get output signal type
-p [1-4] (output port[1-4]); default value is 1
15:Set output signal type
-p [1-4],[0-1],[0-3],[0-1]
(output port[1-4]: Output port 1-4,
signal type[0-1]: 0=TTL, 1=DIFF,
mode[0-3]: 0=From Fiber Input Port, 1=From Port 1 Input, 2=From
IRIG-B encode(Internal RTC), 3=From PPS encode;
inverse[0-1]: 0=No inverse, 1=Inverse)
default value is 1,1,2,0
16:Get Digital Output
-p [0-3] (digital output port[0-3]); default value is 0
17:Set Digital Output
-p [0-3],[0-1] (digital output port[0-3],level[0-1]); default value is 0,0
18:Get Digital Input
-p [0-2] (digital input port[0-2]); default value is 0
The following table describes the function IDs.
Function ID Function description Parameters
0 Display the hardware device ID. For example,
Hardware ID = 1 (DA_IRIGB_4DIO_PCI104)
N/A
1 Display current internal RTC time.
N/A
2 Set internal RTC time yyyy,MM,dd,hh,mm,ss
Where
yyyy is the year (2000 – 2099).
MM is the month (1-12).
dd is the day of the month (1-31).
hh is the hour of the day (0 -23).
mm is the minute (0-59).
ss is the second (0-59).
3 Display the RTC synchronization source. N/A
4 Set the RTC synchronization source. Source [0|2]
Where
0 is free run.
2 is port 1 input.
