DA-IRIGB-4DIO-PCI104-EMC4 Module Driver and Utility Installation
3-8
root@Moxa:~# mxIrigUtil -f 2 -p 2014,11,19,11,19,50
Set IRIGB RTC = 2014/11/19 11:19:50
The following command example displays the IRIG-B module time sync source setting. In this example, the
time source is IRIG-B Port 1.
root@Moxa:~# mxIrigUtil -f 3
Get Sync. Source = 2 (Port 1 In)
The following command example sets the IRIG-B module time sync source.
root@Moxa:~# mxIrigUtil -f 4 -p 1
Set Sync. Source = 1
The following command displays the IRIG-B signal status.
root@Moxa:~# mxIrigUtil -f 5 -p 1
Fiber In Signal Status = 1(Off Line)
root@Moxa:~# mxIrigUtil -f 5 -p 2
Port 1 In Signal Status = 2(Frame Error)
root@Moxa:~
The following command displays the pulse per second width (ms).
root@Moxa:~# mxIrigUtil -f 10
Get PPS Width = 0 ms
The following command example sets the pulse per second width (ms).
root@Moxa:~# mxIrigUtil -f 11 -p 5
Set PPS Width = 5 ms
The following command example displays the input interface.
root@Moxa:~# mxIrigUtil -f 12 -p 1
Get Input Port 1 Interface = 1(DIFFERENTIAL), Inverse = 0
The following command example displays the digital output interface.
root@Moxa:~# mxIrigUtil -f 16 -p 0
Get DO 0 = 1
root@Moxa:~# mxIrigUtil -f 16 -p 1
Get DO 1 = 1
root@Moxa:~# mxIrigUtil -f 16 -p 2
Get DO 2 = 1
root@Moxa:~# mxIrigUtil -f 16 -p 3
Get DO 3 = 1
root@Moxa:~# mxIrigUtil -f 16 -p 4
Get DO 4 = 1
The following command example sets the digital output interface.
root@Moxa:~# mxIrigUtil -f 17 -p 0,0
Set DO 0 = 0
root@Moxa:~# mxIrigUtil -f 17 -p 0,1
Set DO 0 = 1
root@Moxa:~# mxIrigUtil -f 17 -p 1,0
Set DO 1 = 0
root@Moxa:~# mxIrigUtil -f 17 -p 1,1
Set DO 1 = 1
root@Moxa:~# mxIrigUtil -f 17 -p 2,0
Set DO 2 = 0
root@Moxa:~# mxIrigUtil -f 17 -p 2,1
Set DO 2 = 1
root@Moxa:~# mxIrigUtil -f 17 -p 3,0
Set DO 3 = 0
