DA-681-CE Series WinCE User’s Manual System Recovery
6. Reboot the system, the new firmware will be ready to run.
Recovery Procedure
This section describes the recovery procedure. Please follow the steps below.
Recovery Environment
The recovery environment includes the DA-681-CE embedded computer and a bootable USB disk
with the recovery programs and system image file.
USB Port
DA-681-CE
Bootable USB DISK
(Recovery programs
and system image file
included)
Step 1: Format an Empty USB Disk.
One of two methods can be used to create a bootable USB disk:
Method 1: Use the HP USB Disk Format Tool.
4-4
