www.moxa.com
Wireless Computers
MAR-2000 Series
Industrial multi-radio mobile access and applications router
Overview
Appearance
The MAR-2000 is a compact, simple, and programmable RISC-based
wireless mobile router with strong wireless routing capabilities. With
a built-in GPS module, HSPA+ cellular and 802.11a/b/g/n wireless
capabilities, independent power switches on its cellular module
connectors, and high thermal tolerance, the MAR-2000 is compliant
with a portion of EN 50155 specifications. The built-in 32 MB NOR
Flash ROM and 512 MB SDRAM give you enough memory for
installing your own application software, the 512 MB NAND Flash can
be used to provide additional data storage, and the CompactFlash
socket is available for adding more memory when needed. The built-in
GPS module supports geo-fencing functionality, making it ideal for
managing wireless connections in cross-WAN environments often
associated with rolling stock and other vehicular applications.
When a train travels to a different region, it often encounters switches
that support different wireless interfaces, such as Wi-Fi, UMTS, and
HSPA+. The MAR-2000 uses multiple-WAN support and backup
functionality to ensure that your wireless connections are always
available, stable, and reliable.
As an added bonus, the MAR-2000 series includes wide temperature
models designed to operate reliably in extreme environments with
temperatures ranging from -25 to 70°C.
Front View Rear View
DI x 4
DO x 4
Power Input
LED Indicators
(Power, Programmable,
Ready, Storage)
10/100 Mbps
Ethernet Ports x 2
SIM Card Cover
Ethernet
LED Indicators x 4
Power Input
Pin Assignment
Ethernet Port
Pin Assignment
Serial Ports x 2, DB9
(RS-232/422/485)
USB 2.0
Ports x 2
Reset Button
Wireless Antenna Connectors x 7 (Wi-Fi, 3G, GPS)
LED Indicators x 4
(Tx, Rx)
Configuration
Switch
› Dynamic routing across multiple WANs
› Policy-based routing management
› Simple Web management user interface
› IEEE 802.11a/b/g/n wireless AP/bridge/client
› Five-band UMTS/HSPA+ and quad-band GSM/GPRS/EDGE
industrial IP-modems
› Complies with a portion of EN 50155 specifications
› Built-in 50-channel GPS for location-based applications
› -25 to 70°C wide temperature range (EN 50155 Class T3)
