2  D-Link DAP-3310/DAP-3410 Quick Install Guide

ENGLISH

Quick Install Guide

This installation guide provides basic

instructions for installing the DAP-3310/

DAP-3410

Wireless N Exterior Access Point

on your network. For additional information

about how to use the Access Point, please see

the datasheet and user manual from the D-Link

support website.

DAP-3310 is a 2.4GHz Single Band AP; DAP-3410 is a 5GHz

Single Band AP.

The DAP-3310/DAP-3410 support the IP65 water/dust-proof

standard. It is recommended that you place the AP under a

roof, shelter, or weather-proof container in severe weather

environment.

STEP 2: Mount the AP to a Pole or Wall

2A: Pole Mounting

2B: Wall Mounting

Minimum System Requirements

Package Contents

- Computer with Windows, MAC OS, or Linux-

based operating system, and an Ethernet

adapter installed

- Internet Explorer 7.0, Mozilla Firefox

version

12.0, Safari 4.0, or Chrome 20.0 or newer

- DAP-3310/DAP-3410 Wireless N Exterior

Access Point

- PoE Injector

- Power Adapter (48 V/0.5 A)

- Pole Mount (Non-detachable)

- Wall Mount

- Two Plastic Mounting Ties

If any of the above items are missing, please

contact your reseller.

Physical Installation

STEP 1: Connect an Ethernet Cable

to the

LAN (PoE) Port on the AP.

Ethernet cable is not included in the package
